Roland CUBE 30 Service Notes

9
CUBE-30
Table A
100 / 117V SB 1A 250V
➔
100 / 117V
SB 1A 250V
230 / 240V T500mAL 250V 230 / 240V T 500mAL 250V
DIODE
SD000044 LED GREEN D13 on CB 1
SD000045 LED RED D14 on CB, D7 on MB 1
POTENTIOMETER
SD000055 RK09L1120 10KB 9MM ROTARY VR 1,2,3 on CB, V R4,5,6,7,8 on MB 8
FUSE,FUSE HOLDER
# SD000008 5ST 500MA/250V FUSE FH1 on PS1B 1
TRANSFORMER
#
SD000064 ST-11544 230V/240V TRANSFORMER 1
# SD000065 ST-11545 100V/117V TRANSFORMER 1
AC CORD ASSY (Installed)
SD000012 SP-023 230V AC CORD 1
SD000014 SP-301 117V AC CORD 1
SD000015 SP-502B 240V AC CORD 1
SD000016 SP-60 230VE AC CORD 1
SCREWS
40011756 FLANGE HEX NUT M3 ZC AC CORD BUSH, POWER IC 4
SD000067 SCREW 3X12 TRUSS TAPTITE A1 BZC CORNER PROTECTOR 29
SD000068 SCREW 4X25 TRUSS TAPTITE A1 BZC GRILL, CHASSIS 8
40012878 SCREW M3X10 PAN MACHINE W/SW+PW ZC POWER IC 2
40017934 SCREW M3X6 PAN MACHINE W/SW+PW FE ZC
PCB
4
40012945 SCREW M3X6 PAN MACHINE W/SW+PW BZC STAND OFF NUT 2
40345534 SCREW M4X25 PAN MACHINE W/SW+PW BZC AC CORD HOOK 2
SD000052 SCREW 4X8 PAN MACHINE BZC AC CORD GND,WIRING GND 3
SD000047 SCREW 3X8 OVALHEAD MACHINE BZC BADGE 2
SD000048 SCREW 5X35 OVALHEAD MACHINE BZC HANDLE 2
22150518 STANDOFF HEX.BOSS 5.5X15 M3 PCB 2
40011889 EXTERNAL TOOTH WASHER M4 FECM AC CORD GND,WIRING GND 3
40011767 FLANGE HEX NUT M4 FE CM TRANSFORMER PCB WIRING 4
40011689 SPEED NUT M3 F-TYPE BADGE 2
40010189 SCREW 3X8 BINDING ZC AC CORD BUSH 2
SD000018 SCREW 4X12 BINDING MACHINE BZC TRANSFORMER 2
SD000019 SCREW 4X25 BINDING MACHINE BZC SPEAKER 4
SD000042 JACK NUT JACK 4
17048630 VR ACCESSORY NUT M9 VR, ROTARY SW 9
17048631 VR ACCESSORY WASHER M9 VR, ROTARY SW 9
SD000069 WASHER M4 11FAI ADDITIONAL PLASTIC WASHER GRILL 4
40347534 M4 SPRING WASHER BZC TRANSFORMER 2
PACKING
SD000046 MIRAMIT SHEET 1
# SD000049 PACKING BAG 1
# SD000050 PACKING CASE 1
SD000051 PACKING INNER 4
MISCELLANEOUS
SD000058 ADHESIVE SC608LVZ Wring for primary power transformer and
PS1 BOARD.
12369410RT AC CORD HOLDER 1702B AC CORD 2
SD000029 CABLE TIE 6
ACCESSORIES (Standard)
#
SD000003 OWNER’S MANUAL JAPANESE
# SD000004 OWNER’S MANUAL ENGLISH
PWB ASSY

Roland CUBE 30 Specifications

General

Power Output	30W
Inputs	1 x 1/4" (Guitar), 1 x 1/8" (Aux In)
Outputs	1 x 1/4" (Headphones/Line Out)
Dimensions	17.5 x 16.5 x 9.5 inches
Weight	22 lbs
Amp Modeling	Yes
Speaker	10-inch
Effects	Chorus, Flanger, Phaser, Tremolo, Delay, Reverb
EQ	3-band (Bass, Middle, Treble)
Technology	Solid State
Controls	Gain, Volume, Bass, Middle, Treble
