8
Jul.2002
PARTS LIST
fig.part1e
Safety Precautions
The method of replacing the damaged power supply cord vary with serial numbers.
Please refer to followings.
1.
Up to serial No.ZP90419(100V) and NO. ZQ02579(117V,230V) and ZP91179(240V)
Replace power supply cord and PS-1 BOARD when replacing the damaged power supply cord.
Do not replace only power supply cord due to preventing the damage of the traces of the PS-1 BOARD by heating of the soldering iron.
NOTE: Use only the power supply cord and PS-1 BOARD served by Roland Service Center Japan.
Please order the components to Roland Service Center Japan.
PCB ASSY (P/No.SD000001) includes the PS-1 BOARD.
2.
From serial No.ZP90420(100V) and NO. ZQ02580(117V,230V) and ZP91180(240V)
Please replace only the damaged power supply cord according to “Cautions for the replacement of damaged power supply cord.”
CASING
Q’ty
SD000017 BADGE 1
# SD000034 GRILL 1
SD000035 HANDLE WITH ESCUTHEON 1
# SD000028 CABINET ASSY 1
CABINET ASSY includes the following parts.
SD000031
CORNER PROTECTOR 4
# SD000066 TRIM 1
CHASSIS
22360705 CORD HOOK 2
# SD000030 CHASSIS 1
KNOB,BUTTON
2249752100 PUSH BUTTON BLACK #521 1
SD000043 KNOB 9
SWITCH
02897801 SDDJE13200 94V-0 SEESAW SWITCH SW1 1
# SD000061 SRBV17 ROTARY SWITCH SW3 on RSWB 1
SD000059 SPUP128100 PUSH SWITCH SW2 on CB 1
JACK,EXT TERMINAL
13449252 YKB21-5006 (STEREO W/SW) 6.5MM JACK JK2 on MB 1
13449145 YKB21-5010 6.5MM JACK JK3 on MB, JK4 on CB 2
13449146 YKB21-5012 (W/SW) 6.5MM JACK JK1 on CB 1
SPEAKER,BUZZER
#
SD000033 SPEAKER 364510 1
PWB ASSY
#
SD000001 PCB ASSY 100/117V 1
PCB ASSY includes the following parts
SD000053 PCB SPACER SCC-6 94V-0 HEATSINK 3
# SD000036 HEATSINK 1
******** PS-1 BOARD 1
PCB ASSY 100/117V is exclusively for 100/117V use.
For 230/240V, make the following modifications to this “Low Voltage PWB”.
1.Replace fuse to specific one.
2.Write the mark in the specification voltage(230/240V) table of PCB ASSY. See Table A.
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CONSIDERATION ON PARTS ORDRING
When ordering any parts listed in the parts list, please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or even
undelivered replacement.
NOTE: The parts marked # are new. (initial parts)
To Next Page
