16
Oct. 2010 CUBE-40XL
2. Switch Test
Entering the Switch Test makes all LEDs go out.
Carry out operations in the sequence shown below and check the status of the corresponding LEDs.
1. Pressing the SELECT switch makes the LEFT (JC CLEAN), CENTER, and RIGHT (LEAD) LED light up.
2. Pressing the TUNER switch makes the TUNER LED light up.
3. Pressing the REC/PLAY/DUB switch makes the REC/PLAY/DUB LED light up red.
4. Pressing the TAP/STOP switch makes the REC/PLAY/DUB LED light up green.
5. Pressing the TAP/STOP switch again makes the REC/PLAY/DUB LED light up orange.
6. Pressing the SOLO ON/OFF switch makes the SOLO LED light up.
7. Pressing the POWER SQUEEZER switch makes the POWER SQUEEZER LED light up.
8. Operate the rotary switch, plug, and pedal as the order in the following table.
LEDs with “o” in the table will light.
* If you mistake the order of operations or operate more than one item at a time, LEDs of LEFT (JC CLEAN) and RIGHT (LEAD) will blink.
o: illuminated, -: dark
o: illuminated, -: dark
All operations are finished, LEDs of LEFT (JC CLEAN), CENTER and RIGHT (LEAD) will blink.
9. Press FOOT SW [SELECT] to advance to the next test item.
Operation
Lighting LED
LEFT
(JC CLEAN)
CENTER
RIGHT
(LEAD)
Rotate rotary switch
1 ACOUSTIC SIM o o o
2 BLACK PANEL o - -
3 BRIT COMBO - - o
4 TWEED o - -
5 CLASSIC STACK - - o
6 METAL STACK o - -
7 R-FIER STACK - - o
8 EXTREME o - -
9 DYNA AMP - - o
10 EXTREME o - -
11 R-FIER STACK - - o
12 METAL STACK o - -
13 CLASSIC STACK - - o
14 TWEED o - -
15 BRIT COMBO - - o
16 BLACK PANEL o - -
17 ACOUSTIC SIM o o o
Insert a dummy plug
18 Insert into RECORDING OUT/PHONES o - -
19 Pull out o o -
Operation
Lighting LED
LEFT
(JC CLEAN)
CENTER
RIGHT
(LEAD)
EFX
DELAY/
LOOPER
REVERB
Press pedal, pull out/insert plug.
20 Press FOOT SW [TIP: SELECT]. o - - o - -
21 Press FOOT SW [RING: SOLO]. o o - o - -
22 Pull out from FOOT SW (SELECT/SOLO). - - - - - -
23 Insert to FOOT SW (EFX/REVERB). o - - - o -
24 Press FOOT SW [TIP: EFX]. o o - - o -
25 Press FOOT SW [RING: REVERB]. o o o - o -
26 Pull out from FOOT SW (EFX/REVERB). - - - - - -
27 Insert to FOOT SW (DELAY/TAP). o - - - - o
28 Press FOOT SW [TIP: DELAY]. o o - - - o
29 Press FOOT SW [RING: TAP]. o o o - - o
30 Pull out from FOOT SW (DELAY/TAP). - - - - - -
31 Insert to FOOT SW (SELECT/SOLO). o o o o o o
