11
Dec. 2017 E-X20, E-X20A
Test 5: Pedals Inspection
When switch to the Test 5, The LCD will display: Ped Test
When the pedals checks are passed, the LCD will display “PASS”.
At this time, you can press and hold [START/STOP] button then press
[+] button to enter into Test 6.
Test 6: ADC Inspection
When switch to the Test 6, the LCD will display: Adc Test L
Press the [+] button, and then rotate the master volume knob can start the
ADC inspection, and you should rotating it left and right (need to reach
the MIN and MAX), and the LCD will display the ADC value real-time.
For example, if the brilliance knob rotates to the middle position, the
LCD will display the ADC value: 127
When the master volume knob was rotated to MIN and MAX (ADC
value is 000 and 127), the LCD will display: ADC-PIT
When the pitch-bend was up to MIN and MAX (ADC value is 000 and
127), the LCD will display: PASS
At this time, you can press and hold [START/STOP] button then press
[+] button to enter into Test 7.
* If the current ADC check is failed, then the test will stop at the current position
until the current error to be solved.
* Once starting the ADC inspection (when has rotated the knob), you should
finish this test before you switch to other test items.
Test 7: Audio Test Signal Inspection
When switch to the Test 7, the LCD will display:
You can press the specific key ([C4]–[C#5]), to select output specific audio
test signal, and the LCD will indicate current audio test signal. For
example:
All the audio test signals are shown as the following table:
When you press other keys, such as [C3], it will stop output the audio test
signal, the LCD will display: AU:OFF. At this time, you can check the
static noise level of the piano.
When the piano output the maximum undistorted signal, rotate the
volume knob left or right, you can check that the volume knob whether is
OK.
In Test 7 mode, you can press and hold [START/STOP] button then press
[+] button to enter into Test 8.
Test 8: Data Interface and Memory
Inspection
When switch to the Test 8, the LCD will temporary display: BACK:RUN.
It means the background inspection was running. And then, the LCD will
show the test results.
If there is any item failed during the inspection, the LCD will display the
failed item, and the piano would sound a prompt tone “Cymbal”.
For example, if the second item is failed, the LCD will display: ROM
If no item is failed, the LCD will display: PASS, and the piano would
sound a prompt tone “Clave”. Test 8 inspection items are shown as
following table.
* All the inspection items of Test 8 are processed in the background and the
examination completes automatically, and it is started when the system power
on. So, if you want to recheck it, you should restart the digital piano and enter
into the system self-test again.
No.
Key
position
Audio test signal LCD display
1 C4 Left phase (1 kHz sine wave) PAN_L
2 C#4 Right phase(1 kHz sine wave) PAN_R
3 D4
Max undistorted signal (L: 1 kHz
sine wave, R: 440 Hz sine wave)
ALOSSLESS
4 D#4 1 kHz sine wave SIN1KHz
5 E4 Church Organ CH_ORGAN
6 F4
Sweep signal 1 (range: 20 Hz–320
Hz)
SW_FRE_1
7 F#4
Sweep signal 2 (range: 320 Hz–
4800 Hz)
SW_FRE_2
8 G4 White noise WHINOISE
9 G#4 100 Hz sine wave SIN100Hz
10 A4 300 Hz sine wave SIN300Hz
11 A#4 440 Hz sine wave SIN440Hz
12 B4 10 kHz sine wave SIN10KHz
13 C5 AP test signal (IMD) AP_IMD
14 C#5 AP test signal (MultiTone) AP_MULTI
NO. content LCD display
1 A2S-RAM RAM
2 A2S-ROM ROM
