Roland Fantom-X6 Service Notes

19
FANTOM-X6
01450490 NTH5G1M33B103J THERMISTOR RESISTOR R519 on PANEL-C BOARD 1
03128889 EXBV8V222JV RESISTOR-ARRAY RA502,RA503,RA504,RA501 on PANEL-C
BOARD
4
15399561 RPC18T 330 J CARBON RESISTOR R61 on JACK BOARD 1
15399567 RPC18T 560 J CARBON RESISTOR 4
15399573 RPC18T 101 J CARBON RESISTOR R226 on JACK BOARD 1
15399583 RPC18T 271 J CARBON RESISTOR R68,R67 on JACK BOARD 2
15399565 RPC18T 470 J CARBON RESISTOR R221,R65,R220,R222,R64,R62,R63,R219 on
JACK BOARD
8
00566956 RPC05T 390 J MTL.FILM RESISTOR R70,R69 on JACK BOARD 2
00567001 RPC05T 750 J MTL.FILM RESISTOR R235,R126 on JACK BOARD 2
00567034 RPC05T 121 J MTL.FILM RESISTOR R75 on JACK BOARD 1
00567078 RPC05T 271 J MTL.FILM RESISTOR R72,R90 on JACK BOARD 2
00567089 RPC05T 331 J MTL.FILM RESISTOR R206,R232,R168,R153,R140,R130,R211 on
JACK BOARD
7
00567212 RPC05T 332 J MTL.FILM RESISTOR R115,R170,R166,R158,R151,R143,R137,R132
,R122,R210,R214,R215,R233,R205,R128 on
JACK BOARD
15
00567256 RPC05T 562 J MTL.FILM RESISTOR R119,R118,R112,R111 on JACK BOARD 4
00567323 RPC05T 223 J MTL.FILM RESISTOR R163,R164,R180,R181 on JACK BOARD 4
00567334 RPC05T 273 J MTL.FILM RESISTOR R60,R52 on JACK BOARD 2
00567345 RPC05T 333 J MTL.FILM RESISTOR R94,R107,R104,R101,R98 on JACK BOARD 5
00567390 RPC05T 683 J MTL.FILM RESISTOR R109 on JACK BOARD 1
00567401 RPC05T 823 J MTL.FILM RESISTOR R93 on JACK BOARD 1
00567423 RPC05T 124 J MTL.FILM RESISTOR R103 on JACK BOARD 1
15399501 RPC18T 0R0 J MTL.FILM RESISTOR R66 on JACK BOARD 1
15399952 MCR50JZH470 1/2W CHIP RESISTOR R121,R189,R188,R114 on JACK BOARD 4
00126134 EXB-A10E103J RESISTOR ARRAY RA9,RA11,RA17,RA14,RA7,RA5,RA12 on
JACK BOARD
7
01906656 MNR14 EOAB J 000 RESISTOR-ARRAY RA19,RA18 on JACK BOARD 2
01906667 MNR14 EOAB J 100 RESISTOR-ARRAY RA3,RA6,RA2,RA24,RA25,RA4 on JACK
BOARD
6
+22
01906678 MNR14 EOAB J 103 RESISTOR-ARRAY RA1,RA16 on JACK BOARD 2
+8
13749190 SR50TR 100 J CARBON RESISTOR R8,R7 on PANEL-A BOARD 2
13749765T0 SR25TRE 470 J CARBON RESISTOR R23 on PANEL-A BOARD 1
13749771T0 SR25TRE 820 J CARBON RESISTOR R22 on PANEL-A BOARD 1
13749773T0 SR25TRE 101 J CARBON RESISTOR R2,R13,R4,R3,R1 on PANEL-A BOARD 5
13749779T0 SR25TRE 181 J CARBON RESISTOR R17 on PANEL-A BOARD 1
13749781T0 SR25TRE 221 J CARBON RESISTOR R21,R16 on PANEL-A BOARD 2
13749797T0 SR25TRE 102 J CARBON RESISTOR R14,R19 on PANEL-A BOARD 6
13749799T0 SR25TR 122J CARBON RESISTOR R15 on PANEL-A BOARD 1
13749805T0 SR25TRE 222 J CARBON RESISTOR R6 on PANEL-A BOARD 1
13749811T0 SR25TRE 392 J CARBON RESISTOR R5,R10 on PANEL-A BOARD 2
13749821T0 SR25TRE 103 J CARBON RESISTOR R30,R28,R26,R18,R11,R24 on PANEL-A
BOARD
6
13749837T0 SR25TRE 473 J CARBON RESISTOR R12 on PANEL-A BOARD 1
13749839T0 SR25TRE 563 J CARBON RESISTOR R20 on PANEL-A BOARD 1
13749859T0 SR25TRE 394 J CARBON RESISTOR R9 on PANEL-A BOARD 1
02457790 MNR14 EOAB J 330 RESISTOR-ARRAY 2
POTENTIOMETER
# 03562256 EVUF2AE20B14 ROTARY POTENTIOMETER VR501 on PANEL-C BOARD 1
03126178 EVUF2JFK3B14
9M/M ROTARY POTENTIOMETER
VR6,VR5,VR2,VR4 on PANEL-A BOARD 4
03126167 EVJY10FB6A24
12M/M ROTARY POTENTIOMETER
VR1,VR3 on PANEL-A BOARD 2
CAPACITOR
01674190 ECUV1H150JCV CERAMIC CAPACITOR C71,C27,C72,C164,C165,C263,C264,C440,C
441,C26 on MAIN BOARD
10
01674423 ECUV1H471JCV CERAMIC CAPACITOR C140 on JACK BOARD ,C25,C24 on MAIN
BOARD
2
+1
01674689 ECJ1VF1H473Z CERAMIC CAPACITOR C283,C318 on MAIN BOARD 2
01674712 ECJ1VF1A105Z CERAMIC CAPACITOR C104,C61 on JACK BOARD ,C75,C290 on
MAIN BOARD
2
+2
02129534 ECJ1VB1H102K CERAMIC CAPACITOR C189,C188,C21,C224,C44 on JACK BOARD
,C386 on MAIN BOARD
1
+5
01674701 ECJ1VF1E104Z 0.1UF/16VK CERAMIC CAPACITOR C30,C21,C22,C23,C26,C27,C33,C29,C31,C20
,C11,C28,C19,C18,C16,C15,C14,C12,C34,C1
0,C9,C8,C7,C1,C13,C32 on EXP BASE
BOARD,
C220,C101,C107,C108,C111,C227,C222,C30,
C70,R228,C206,C60,C62,C64,C65,C10,C68,C
12,C72,C73,C99,C26,C66,C144,
275
C8,C185,C211,C116,C120,C205,C131,C194,
C183,C171,C172,C174,C176,C181,C178,C18
0,C128,C115,C114,C7,C29,C6 on JACK
BOARD
,C443,C225,C224,C442,C196,C450,C192,C19
1,C190,C186,C183,C199,C449,C451,C452,C4
53,C454,C455,C181,C222,C460,C462,C470,C
472,C444,C122,C171,C129,C128,C127,C125,
C201,C131,C123,C132,C121,C120,C119
RESISTOR

Roland Fantom-X6 Specifications

General

Keyboard	61 keys (with velocity and channel aftertouch)
Polyphony	128 voices
Wave Memory	128 MB (16-bit linear equivalent)
User Patches	256
User Rhythm Sets	32
Preset Performances	64
User Performances	64
Arpeggiator	Yes
Preset Patches	1, 024 + 256 (GM2)
Preset Rhythm Sets	40 + 9 (GM2)
Effects	Reverb, chorus
Display	320 x 240 backlit LCD
Sequencer	16-track sequencer with 480 TPQN resolution
Sampling	Yes (up to 544MB RAM with optional DIMM)
Expansion Slots	4 SRX expansion slots
USB	USB MIDI
Weight	12.5 kg (27 lbs 9 oz)
Connectivity	MIDI, USB, line in/out, headphone, pedal
Storage	CompactFlash slot
Power Supply	AC 117 V, AC 230 V (50/60 Hz)
