Page #13 background imageLoading...
Page #13 background image
14
Mar.2004
PARTS LIST
fig.part1e
CASING
#
03567790 DISPLAY CUSHION 4
03122045 SIDE COVER R 1
03122034 SIDE COVER L 1
# 03565245 DISPLAY ESCT 1
03122067 RUBBER SW ESCT 1
03126556 END BLOCK 1
03126567 BENDER PANEL 1
# 03562134 TOP PANEL 1
# 03562112 DISPLAY COVER 1
03017778 EXP COVER 1
# 72235056 BOTTOM COVER ASSY 1
NOTE: ‘BOTTOM COVER ASSY’ includes the following parts.
******** BOTTOM COVER 1
12359139 RUBBER FOOT FF-018 BLK 4
CHASSIS
#
03562123 DISPLAY HOLDER 1
02674034 PANEL HOLDER 2
03125812 SIDE HOLDER R 1
03125801 SIDE HOLDER L 1
03125845 PWR SPLY HOLDER 1
KNOB, BUTTON
01234090
D T-KEYTOP MX4B BLK 1
# 03565234 J R-KNOB SF-ELA BLK/SLV 6
22485303 D R-KNOB(ALPHA-DIAL) L BLK 248-303 1
# 03562145 RUBBER SW 1
32490595 P S-KEY MX BLK 1
SWITCH
01340290
TACT SWITCH EVQ11A H=5.0 SW2,SW3,SW13,SW20,SW19,SW18,SW17,S
W16,SW1,SW14,SW4,SW12,SW11,SW10,S
W8,SW7,SW6,SW5,SW15 on PANEL-A
BOARD,
SW201,SW202,SW203,SW204,SW210,SW20
5,SW206,SW207,SW208,SW209 on PANEL-
B BOARD,
23
+10
+19
SW516,SW503,SW518,SW514,SW513,SW51
2,SW520,SW515,SW521,SW522,SW523,SW5
19,SW506,SW511,SW501,SW517,SW505,SW
507,SW508,SW509,SW510,SW502,SW504 on
PANEL-C BOARD
00894645 TACT SWITCH SKECAF WITHOUT LED SW21,SW23,SW22 on PANEL-A BOARD 3
JACK, EXT TERMINAL
02781189
USB CONNECTOR YKF45-0021 JK1 on MAIN BOARD 1
02900867 CARD EJECTOR SCAB1A5600 1
02900834 CARD CONECTR SCAA1A2300 CN1 on PC CARD BOARD 1
13429274 MIDI SOCKET YKF51-5041 JK1 on JACK BOARD 1
03231812 RCA(PIN) YKC21-4173 JK12 on JACK BOARD 1
13449258 6.5MM JACK HLJ4306-01-3080 JK7 on JACK BOARD 1
13449275 6.5MM JACK YKB21-5074 JK2,JK3 on JACK BOARD 2
13449283 6.5MM JACK HLJ7101-01-3010 JK9,JK10,JK8,JK11 on JACK BOARD 4
13449284 6.5MM JACK HLJ7001-01-3010 JK6,JK4 on JACK BOARD 2
DISPLAY UNIT
#
03560889 KCG057QV1DB-G00 LCD 1
NOTE: Replacement KCG057QV1DB-G00 should be made on a unit base.
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CONSIDERATION ON PARTS ORDRING
When ordering any parts listed in the parts list, please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or even
undelivered replacement.
NOTE: The parts marked # are new. (initial parts)
