Roland Fantom-X6 Service Notes

15
FANTOM-X6
POWER SUPPLY UNIT
01785823 A1DU2L3B034 SWITCHING REGULATOR 1
NOTE: Replacement A1DU2L3B034 should be made on a unit base.
BENDER UNIT
03234723 PB-H0204 BENDER 1
NOTE: Replacement PB-H0204 should be made on a unit base.
KEYBOARD ASSY
# 72568667 SK-961-L KEYBOARD ASSY 1
NOTE: See ‘KEYBOARD PARTS LIST’ for details.
PCB ASSY
# 72564734 MAIN BOARD ASSY 1
NOTE: ‘MAIN BOARD ASSY’ includes the following parts.
# 03670034 SHEET K4E(10)-23X20T15S 1
# 03670045 SHEET K4E(10)-55X15T15S 1
NOTE: When you replace the MAIN BOARD ASSY for repairng, be sure to perform the
"MAIN BOARD SETTING FOR SELECTING MODEL PROCEDURE"(to see P24).
In addition, we supply the MAIN BOARD ASSY of FANTOM-X6 setting for spare parts.
# 72564245 PC CARD BOARD ASSY 1
NOTE: ‘PC CARD BOARD ASSY’ includes the following parts.
# 03562156 PC CARD ESCUTCHEON BLK 1
# 03562167 PC CARD HOLDER HOLDER 1
40343367 SCREW M2X14
PAN MACHINE W/SW+SMALL PWZC
4
# 72564334 PANEL-C KEYTOP ASSY 1
NOTE: ‘PANEL-C KEYTOP ASSY’ includes the following parts.
01783923 N S-KEYTOP MD1H 4
02013090 F C-KEYTOP MX1H CLR 1
03120889 D S-KEYTOP SX2H-B GRS 2
03120890 D S-KEYTOP SX1H-B GRS 10
02123012 ENCODER HOLDER 1
# 72564323 JACK BOARD ASSY 1
NOTE: ‘JACK BOARD ASSY’ includes the following parts.
40342856 COATING CLIP CP-1S 3
# 72564312 INLET BOARD ASSY 1
# 72564223 LCD BOARD ASSY 1
# 72564212 INVERTER BOARD ASSY 1
# 72564278 PANEL-B KEYTOP ASSY 1
NOTE: ‘PANEL-B KEYTOP ASSY’ includes the following parts.
03120889 D S-KEYTOP SX2H-B GRS 4
03120890 D S-KEYTOP SX1H-B GRS 2
# 72564256 PANEL-A KEYTOP ASSY 1
NOTE: ‘PANEL-A KEYTOP ASSY’ includes the following parts.
01343089 ESCUTCHEON
D-BEAM CONTROLLER ESCT BLK
1
# 03565223 KEYTOP REC 1
# 03565212 KEYTOP PLAY 1
# 03565190 KEYTOP STOP 1
03120890 D S-KEYTOP SX1H-B GRS 16
03120889 D S-KEYTOP SX2H-B GRS 1
01783923 N S-KEYTOP MD1H 1
12169368 LED SPACER LDS-40B 1
12169406 LED SPACER 6
02230578 LED SPACER LDS-50R 1
01455901 LED SPACER LH-36-9 1
72235090 EXP BASE BOARD ASSY 1
NOTE: ‘EXP BASE BOARD ASSY’ includes the following parts.
02019034 PWB SPACER RSPLS-12L 4
01902756 PWB SPACER RSPS-12L 4
IC
02903723 HD6417706 IC (32BIT CPU) IC1 on MAIN BOARD 1
02900978 M66291GP IC (USB CONTROLLER) IC56 on MAIN BOARD 1
# 03456167 S1D13705F00A200 IC (LCD-DRIVER CPU PERIPH) IC128 on MAIN BOARD 1
# 03566067 T6TV2TBG-0002(WX) IC (CUSTOM) IC102 on MAIN BOARD 1
# 03562234 UPD23C128040BLGY-818-MJH IC (MASK ROM) IC103 on MAIN BOARD 1

Roland Fantom-X6 Specifications

General

Keyboard	61 keys (with velocity and channel aftertouch)
Polyphony	128 voices
Wave Memory	128 MB (16-bit linear equivalent)
User Patches	256
User Rhythm Sets	32
Preset Performances	64
User Performances	64
Arpeggiator	Yes
Preset Patches	1, 024 + 256 (GM2)
Preset Rhythm Sets	40 + 9 (GM2)
Effects	Reverb, chorus
Display	320 x 240 backlit LCD
Sequencer	16-track sequencer with 480 TPQN resolution
Sampling	Yes (up to 544MB RAM with optional DIMM)
Expansion Slots	4 SRX expansion slots
USB	USB MIDI
Weight	12.5 kg (27 lbs 9 oz)
Connectivity	MIDI, USB, line in/out, headphone, pedal
Storage	CompactFlash slot
Power Supply	AC 117 V, AC 230 V (50/60 Hz)
