Roland Fantom-X6 Service Notes

16
Mar.2004
# 03562223 UPD23C128040BLGY-819-MJH IC (MASK ROM) IC104 on MAIN BOARD 1
03124978 UPD23C128040ALGY-536-MJH IC (MASK ROM) IC28 on MAIN BOARD 1
03124989 UPD23C128040ALGY-535-MJH IC (MASK ROM) IC33 on MAIN BOARD 1
# 03560589 TC58DVM92A1TG00BBH IC (FLASH MEMORY) IC53 on MAIN BOARD 1
******** MBM29LV160BE70TN-E1 IC (FLASH MEMORY) IC19 on MAIN BOARD 1
03237689 M12L64164A-7T IC (MEMORY DRAM) IC106 on MAIN BOARD 1
03342201 K4S281632E-TC75 IC (SDRAM) IC20,IC2,IC24,IC6 on MAIN BOARD 4
03017590 UDA1351TS IC (DIR DAC) IC75 on MAIN BOARD 1
03231701 AK4527BVQ IC (AD/DA) IC60 on MAIN BOARD 1
01458401 TC74LVX4245FS(EL) IC (TTL) IC114,IC112 on MAIN BOARD 2
# 03459745 HD74LVC540ATELL-E IC (CMOS) IC111 on MAIN BOARD 1
# 03346267 HD74LV273ATELL-E IC (CMOS) IC90 on MAIN BOARD 1
01349590 TC7WU04FU(TE12L) IC (CMOS) IC16,IC26 on MAIN BOARD 2
01677689 HD74HC238FPEL IC (CMOS) IC96 on MAIN BOARD 1
03015390 TC74HCT273AF(EL) IC (CMOS) IC54 on MAIN BOARD 1
03015234 HD74LV32ATELL IC (CMOS) IC113,IC14,IC50 on MAIN BOARD 3
01675034 TC74VHC138FT(EL) IC CMOS IC99,IC98 on MAIN BOARD 2
02675667 HD74LV21ATELL IC (CMOS) IC91 on MAIN BOARD 1
01348956 TC7SH00FU(TE85L) IC (CMOS) IC105 on MAIN BOARD 1
01455312 TC7WH74FU IC (CMOS) IC115 on MAIN BOARD 1
01783523 TC74VHCT245AFT(EL) IC (CMOS) IC119,IC118,IC117 on MAIN BOARD 3
01675023 TC74VHC139FT(EL) IC (CMOS) IC107,IC108,IC110 on MAIN BOARD 3
02129334 TC7WH08FU(TE12L) IC (CMOS) IC120 on MAIN BOARD 1
02451690 HD74LV08ATELL IC (CMOS) IC94 on MAIN BOARD 1
02451912 HD74LV00ATELL IC (CMOS) IC74,IC116 on MAIN BOARD 2
02456756 TC74VHCT04AFT(EL) IC (CMOS) IC9 on MAIN BOARD 1
02675645 HD74LV04ATELL IC (CMOS) IC17,IC10 on MAIN BOARD 2
02675656 HD74LV11ATELL IC (CMOS) IC92 on MAIN BOARD 1
02675689 HD74LV245ATELL IC (CMOS) IC1,IC2,IC3 on EXP BASE BOARD,
IC3,IC44,IC40,IC8,IC7,IC5 on MAIN
BOARD
6
+3
01348945 TC7SH32FU(TE85L) IC (CMOS) IC130 on MAIN BOARD 1
01890367 TC74VHC175FT(EL) IC (CMOS) IC52 on MAIN BOARD 1
15189261 M5218AFP-600E IC (BIPOLAR OP AMP) IC18,IC19,IC16,IC24,IC25 on JACK BOARD
,IC71,IC70,IC68,IC61,IC59 on MAIN
BOARD
5
+5
00344390 TA7805F(TE16L) IC (REGULATOR) IC58 on MAIN BOARD 1
02671545 PQ070XZ01ZP IC (REGULATOR) IC101,IC57 on MAIN BOARD 2
03125089 PQ1CY1032ZP IC (SWITCHING REGULATOR) IC100 on MAIN BOARD 1
01785178 TC9271FS IC (DIGITAL OUT IF) IC62 on MAIN BOARD 1
02900690 P2027A-08TR IC IC89 on MAIN BOARD 1
15199937 M51953BFP-600C IC (RESET) IC18 on MAIN BOARD 1
01783589 HD74HC4052FPEL IC (CMOS) IC14 on JACK BOARD,
IC503,IC501 on PANEL-C BOARD
2
+1
02894301 HA17324ARPEL(FP-14DN) IC (CMOS OP) IC502 on PANEL-C BOARD 1
03127267 HD6433061G45FP IC (16BIT CPU) IC2 on JACK BOARD 1
00129278 SSC1080F0B IC IC5 on JACK BOARD 1
15269219H0 HD74LS05FPEL IC (TTL) IC12 on JACK BOARD 1
01121834 TC7W74FU TE12L IC IC6 on JACK BOARD 1
01783656 HD74HC4053FPEL IC CMOS IC23 on JACK BOARD 1
15249104 TC7S04F(TE85L) IC (CMOS) IC22 on JACK BOARD 1
00567534 TC74VHC138F(EL) IC (CMOS) IC9,IC8 on JACK BOARD 2
# 01908678 TC74VHCU04FT(EL) IC (CMOS) IC17 on JACK BOARD 1
02451712 HD74LV14ATELL IC (CMOS) IC1 on JACK BOARD 1
15289105 UPC4570G2-E2 IC (BIPOLAR OP AMP) IC20 on JACK BOARD 1
15289151 NJM2904M-TE3 IC (OP AMP) IC21,IC15,IC10,IC7 on JACK BOARD 4
02900545 PC410LKNIP IC (PHOTO COUPLER) IC11 on JACK BOARD 1
15189186 UPC4570C IC (BIPOLAR OP AMP) IC4,IC2,IC3 on PANEL-A BOARD 3
01785012 HA17324 IC (BIPOLAR OP AMP) IC1 on PANEL-A BOARD 1
TRANSISTOR
02900778 PW MOSFET XP132A1275SR TRANSISTOR Q17 on MAIN BOARD 1
15309101 2SA1037AKT146R TRANSISTOR Q28 on JACK BOARD ,Q11,Q12 on MAIN
BOARD
2
+1
15329103T0 2SK880-GR(TE85R) FET Q31 on JACK BOARD ,Q7,Q8,Q10,Q9 on
MAIN BOARD
4
+1
00239812 DTC114EUT106 TRANSISTOR Q17,Q16,Q15,Q14,Q13,Q12,Q11,Q10 on
JACK BOARD ,Q14,Q15,Q16,Q18,Q13 on
MAIN BOARD
5
+8
15319101 2SC2412KR T146 TRANSISTOR Q42 on JACK BOARD,
Q501 on PANEL-C BOARD
1
+1
00901523 2SA1681 (SC-62)(POW SW) TRANSISTOR Q34 on JACK BOARD 1
01121289 2SC4081 T106 QRS TRANSISTOR Q23,Q24,Q19,Q18,Q1 on JACK BOARD 5
02671023 2SC3052-T12-1E TRANSISTOR Q41,Q35 on JACK BOARD 2
15319105 2SC3326-A TRANSISTOR Q27,Q40,Q39,Q38,Q37,Q33,Q26,Q25,Q32,Q
30 on JACK BOARD
10
00239801 DTA114EU T-106 TRANSISTOR Q20 on JACK BOARD 1
02451378 RN2427 TRANSISTOR Q3,Q4,Q5,Q6,Q7,Q8,Q9 on JACK BOARD 7
15329533 RN2307(TE85R) TRANSISTOR Q21 on JACK BOARD 1
02671267 RT1N141C-T12-1 TRANSISTOR Q36,Q29 on JACK BOARD 2
15329511 DTC114TKT146 DIGITAL TRANSISTOR Q43 on JACK BOARD 1
15329531 RN1308-TE85R TRANSISTOR Q22 on JACK BOARD 1
IC

Roland Fantom-X6 Specifications

General

Keyboard	61 keys (with velocity and channel aftertouch)
Polyphony	128 voices
Wave Memory	128 MB (16-bit linear equivalent)
User Patches	256
User Rhythm Sets	32
Preset Performances	64
User Performances	64
Arpeggiator	Yes
Preset Patches	1, 024 + 256 (GM2)
Preset Rhythm Sets	40 + 9 (GM2)
Effects	Reverb, chorus
Display	320 x 240 backlit LCD
Sequencer	16-track sequencer with 480 TPQN resolution
Sampling	Yes (up to 544MB RAM with optional DIMM)
Expansion Slots	4 SRX expansion slots
USB	USB MIDI
Weight	12.5 kg (27 lbs 9 oz)
Connectivity	MIDI, USB, line in/out, headphone, pedal
Storage	CompactFlash slot
Power Supply	AC 117 V, AC 230 V (50/60 Hz)
