Roland Fantom-X6 Service Notes

17
FANTOM-X6
03126145 2SA933ASTPR TRANSISTOR Q2 on PANEL-A BOARD 1
15129626 2SD1468S TP Q TRANSISTOR Q3 on PANEL-A BOARD 1
DIODE
01780045 RB051L-40 SCHOTTKY DIODE D4 on MAIN BOARD 1
15339130 MA142WK-(TX) ARRAY DIODE DA1,DA2,DA3,DA4 on JACK BOARD,
DA8,DA6,DA7,DA9 on MAIN BOARD,
DA503,DA505,DA502,DA501,DA504,DA51
3,DA512,DA511,DA510,DA509,DA508,DA5
07,DA506 on PANEL-C BOARD
4
+1
3
+4
01897189 MA147-(TX) ARRAY DIODE DA5,DA6,DA7,DA9,DA11,DA12,DA13,DA
14,DA15,DA8 on JACK BOARD,
DA3,DA2,DA5,DA4 on MAIN BOARD
4
+1
0
02125167 SLI-343DCT32W LED (YELOW) LED15,LED2,LED16,LED11,LED10,LED9,L
ED8,LED7,LED5,LED4,LED3,LED1,LED17
on PANEL-A BOARD,
LED509,LED502,LED510,LED516,LED503
on PANEL-C BOARD
5
+1
3
02894090 SLR-343DUT32 LED (ORNG) LED18 on PANEL-A BOARD,
LED501,LED523,LED508,LED515 on PAN-
EL-C BOARD
4
+1
03122112 SLR-343BBT3F LED(BLUE) LED14 on PANEL-A BOARD,
LED522 on PANEL-C BOARD
1
+1
# 03564390 SML-212DTT86 LED LED520,LED527,LED518,LED528,LED504,L
ED526,LED525,LED524,LED521,LED519,LE
D517,LED514,LED513,LED512,LED511,LE
D507,LED505,LED506 on PANEL-C
BOARD
18
01121323 DA204U T106 DIODE ARRAY DA16 on JACK BOARD 1
01121334 DAN202U T106 ARRAY DIODE DA10 on JACK BOARD 1
00129767 RD10M-T1B B2 ZENER DIODE D1 on JACK BOARD 1
15019126 1SS133 T-77 SWITCHING DIODE D18,D29,D28,D27,D26,D25,D24,D23,D22,D
21,D1,D19,D17,D16,D6,D2,D3,D20,D5,D15,
D7,D8,D10,D11,D12,D13,D14,D4 on PAN-
EL-A BOARD,
D204,D201,D203,D205,D206,D207,D208,D2
09,D210,D202 on PANEL-B BOARD
10
+28
01900612 TPS611 DIODE Q1 on PANEL-A BOARD 1
03126134 TLN233 LED LED23 on PANEL-A BOARD 1
01012078 SLR-332MG3F LED (GREEN) LED19 on PANEL-A BOARD 1
01011656 SLR-332VR3F LED (RED) LED21,LED13,LED12,LED6,LED20 on
PANEL-A BOARD
5
00127367 SPR-39MVW LED (RED/GREEN) LED22 on PANEL-A BOARD 1
RESISTOR
02014945 MCR50 JZH J 0R0 MTL.FILM RESISTOR R407 on MAIN BOARD 1
00567412 RPC05T 104 J MTL.FILM RESISTOR R116,R145,R209,R204,R183,R172,R169,R89,
R157,R142,R134,R131,R95,R83,R76,R56,R12
3,R161 on JACK BOARD,
R420,R227,R222,R211,R208,R199,R172,R415,
R416,R236,R417,R418,R168 on MAIN
BOARD
13
+18
00567289 RPC05T 103 J MTL.FILM RESISTOR R2,R6,R10 on EXP BASE BOARD
,R14,R12,R13,R38,R86,R88,R96,R106,R127,R
135,R148,R165,R202,R203,R207,R208,R10,R
5,R182,R2,R11 on JACK BOARD
62
+1
+21
+3
R118,R119,R134,R139,R150,R164,R165,R166
,R174,R114,R176,R44,R188,R175,R110,R109,
R105,R84,R82,R195,R43,R42,R40,R39,R25,R
13,R414,R80,R437,R393,R395,R413,R428,R4
30,R392,R436,R446,R438,
R445,R449,R453,R455,R238,R396,R431,R266
,R451,R244,R247,R390,R243,R313,R358,R36
3,R364,R365,R381,R241,R384,R387,R388,R2
48 on MAIN BOARD ,R517 on PANEL-C
BOARD
00566867 RPC05T 100 J MTL.FILM RESISTOR R441,R261,R260,R442,R262,R263 on MAIN
BOARD
6
00566912 RPC05T 220 J MTL.FILM RESISTOR R302,R425,R424,R423,R367,R366,R342,R340
,R34,R298,R297,R130,R100,R45,R339,R426,R
341,R300 on MAIN BOARD
18
00566923 RPC05T 270 J MTL.FILM RESISTOR R146,R145 on MAIN BOARD 2
00566934 RPC05T 330 J MTL.FILM RESISTOR R72,R350,R348,R346,R345,R344,R71,R349,R
74,R75,R76,R314,R323,R325,R326,R335,R34
3,R7,R450,R1,R2,R3,R347,R6,R368,R8,R10,R
63,R70,R435,R434,R433,R432,R4 on MAIN
BOARD
34
00566967 RPC05T 470 J MTL.FILM RESISTOR R284,R292,R79,R282,R283,R337,R290,R285,
R400,R338,R401,R294,R293,R291,R289,R288,
R287,R286,R399 on MAIN BOARD,
R514,R513 on PANEL-C BOARD
19
+2
TRANSISTOR

Roland Fantom-X6 Specifications

General

Keyboard	61 keys (with velocity and channel aftertouch)
Polyphony	128 voices
Wave Memory	128 MB (16-bit linear equivalent)
User Patches	256
User Rhythm Sets	32
Preset Performances	64
User Performances	64
Arpeggiator	Yes
Preset Patches	1, 024 + 256 (GM2)
Preset Rhythm Sets	40 + 9 (GM2)
Effects	Reverb, chorus
Display	320 x 240 backlit LCD
Sequencer	16-track sequencer with 480 TPQN resolution
Sampling	Yes (up to 544MB RAM with optional DIMM)
Expansion Slots	4 SRX expansion slots
USB	USB MIDI
Weight	12.5 kg (27 lbs 9 oz)
Connectivity	MIDI, USB, line in/out, headphone, pedal
Storage	CompactFlash slot
Power Supply	AC 117 V, AC 230 V (50/60 Hz)
