Roland Fantom-X6 Service Notes

21
FANTOM-X6
15369152 ECEV1CA100SR CHEMICAL CAPACITOR C4,C3,C2,C6,C25,C5,C17 on EXP BASE
BOARD
7
INDUCTOR, COIL, FILTER
# 03125167 SLF12565T-470M2R4 CHOKE COIL L1 on MAIN BOARD 1
# 03566334 EMI FILTER NFW31SP106X1E4L 1
01565578 N1608Z601T01 FERRITE-BEAD L21,L22,L23,L26,L27,L37,L29,L18,L30,L31,L
33,L35,L36,L28,L10,L1,L2,L3,L4,L5,L20,L7,L
19,L11,L12,L13,L14,L15,L16,L17,L34,L6,L32
on JACK BOARD,
L36,L35,L34,L33,L32,L31,L30,L29,L28,L27,L
26,L8,L20,L24,L23,L7,L22,L6,L21,L25,L19
29
+33
,L14,L13,L12,L11,L10,L9,L37,L5 on MAIN
BOARD
01909645 EXCML16A270U FERRITE-BEAD L4,L3,R237 on MAIN BOARD 3
00903167 N2012Z601T02 (CHIP) FERRITE-BEAD L24,L25 on JACK BOARD 2
CRYSTAL, RESONATOR
15299170 MC-406 32.768KHZ CRYSTAL X1 on MAIN BOARD 1
00894034 MA-406 16.000MHZ TE24 CRYSTAL X2 on MAIN BOARD 1
01340745 MA-406 12MHZ CRYSTAL X4 on MAIN BOARD 1
02673134 MA-406 16.9344MHZ CRYSTAL X3 on MAIN BOARD 1
00894023 MA-406 20.000MHZ TE24 CRYSTAL X1 on JACK BOARD 1
ENCODER
01905467 EVE GC1 F20 24B ROTARY ENCODER EN501 on PANEL-C BOARD 1
CONNECTOR
03126067 18FMN-BMTTN-A-TFT CONNECTOR CN1 on JACK BOARD,
CN9 on MAIN BOARD
1
+1
03230623 54104-5092 CONNECTOR CN18 on MAIN BOARD,
CN2 on PC CARD BOARD
1
+1
# 03345856 34FMN-BMTTN-A-TFT CONNECTOR CN5,CN4 on MAIN BOARD 2
13369592 B7B-XH-A(7P) JST CONNECTOR CN10 on MAIN BOARD 1
13369570 B2B-PH-K-S (2P) CONNECTOR CN403 on INVERTER BOARD,
CN21 on MAIN BOARD
1
+1
13369562 B15B-PH-K-S JST CONNECTOR CN18 on JACK BOARD,
CN22 on MAIN BOARD
1
+1
# 03457478 20FLT-SM1-TB CONNECTOR CN20 on MAIN BOARD 1
03126090 40FMN-SMT-A-TF CONNECTOR CN501 on PANEL-C BOARD 1
01908656 18FE-BT-VK-N CONNECTOR CN13 on JACK BOARD 1
01908645 16FE-BT-VK-N CONNECTOR CN3 on JACK BOARD 1
02782467 10FMN-BTK CONNECTOR CN6 on JACK BOARD 1
03126078 38FMN-BMTTN-A-TFT CONNECTOR CN5 on JACK BOARD 1
03126089 40FMN-BMTTN-A-TFT CONNECTOR CN7 on JACK BOARD 1
03013989 B4B-PH-K-S JST(PB FREE) CONNECTOR CN8 on JACK BOARD 1
13369564 B12B-PH-K-S JST CONNECTOR CN10 on JACK BOARD,
CN11 on PANEL-A BOARD
1
+1
02566489 SM02(8.0)B-BHS-TB CONNECTOR CN304 on LCD BOARD 1
01349645 S2(4-2.3)B-XH-A CONNECTOR CN305 on LCD BOARD 1
02673145 B2(4-2.3)B-XH-A CONNECTOR CN404 on INVERTER BOARD 1
02782478 10FMN-STK CONNECTOR CN201 on PANEL-B BOARD 1
03126034 38FMN-STK-A CONNECTOR CN2 on PANEL-A BOARD 1
03126045 34FMN-STK-A CONNECTOR CN5,CN6 on EXP BASE BOARD 2
02010078 TX25-80P-6ST-E1 CONNECTOR CN4,CN3,CN2,CN1 on EXP BASE BOARD 4
WIRING, CABLE
02344023 WIRING 12X200-P2.0-PHR-PHR-F 1
02342012 WIRING 4X200-P2.0-PHR-PHR-F 1
03129312 BAN CARD BNCD-P=1.00-K-40-700 1
03129301 BAN CARD BNCD-P=1.00-K-10-400 1
03129290 BAN CARD BNCD-P=1.00-K-38-400 1
# 03565290 BAN CARD BNCD-S-P=0.50-K-50-140 1
# 03566590 BAN CARD BNCD-P=1.00-K-18-500 1
03120801 WIRING W3 1
02679390 WIRING 7X150-P2.5-XHP-XHP-F 1
# 03564990 WIRING W3 1
# 03564945 WIRING W2 1
# 03564912 WIRING W1 1
03129334 BAN CARD BNCD-P=1.25-K-18-380 1
03129323 BAN CARD BNCD-P=1.00-K-34-60 2
02128934 BAN CARD BNCD-P=1.25-K-16-320 1
# 03565267 BAN CARD BNCD-P=0.50-K-20-320 1
TRANSFORMER
02019478 (7KQ5) 19832A PULSE TRANS T1 on JACK BOARD 1
CAPACITOR

Roland Fantom-X6 Specifications

General

Keyboard	61 keys (with velocity and channel aftertouch)
Polyphony	128 voices
Wave Memory	128 MB (16-bit linear equivalent)
User Patches	256
User Rhythm Sets	32
Preset Performances	64
User Performances	64
Arpeggiator	Yes
Preset Patches	1, 024 + 256 (GM2)
Preset Rhythm Sets	40 + 9 (GM2)
Effects	Reverb, chorus
Display	320 x 240 backlit LCD
Sequencer	16-track sequencer with 480 TPQN resolution
Sampling	Yes (up to 544MB RAM with optional DIMM)
Expansion Slots	4 SRX expansion slots
USB	USB MIDI
Weight	12.5 kg (27 lbs 9 oz)
Connectivity	MIDI, USB, line in/out, headphone, pedal
Storage	CompactFlash slot
Power Supply	AC 117 V, AC 230 V (50/60 Hz)
