Roland fp-30 Midi Implementation

MIDI Implementation
10
9 System Exclusive Messages
6 Identity Reply
Status Data byte Status
F0H 7EH, 10H, 06H, 02H, 41H, 42H, 00H, F7H
00H, 20H, 00H, 01H, 00H, 00H
Byte Explanation
F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
10H Device ID
(use the same as the device ID of Roland)
06H Sub ID#1 (General Information)
02H Sub ID#2 (Identity Reply)
41H ID number (Roland)
42H Device family code (LSB)
00H Device family code (MSB)
00H Device family number code (LSB)
20H Device family number code (MSB)
00H Software revision level
01H Software revision level
00H Software revision level
00H Software revision level
F7H EOX (End of Exclusive)

Roland fp-30 Specifications

General

Certification	FCC, CE
Sound effects	Ambience, Brilliance
Tones quantity	35
Pedals quantity	1
RMS rated power	24 W
Speaker diameter	120 mm
Number of speakers	2
Metronome tempo range	20 - 250 bpm
Metronome beats per bar	0, 2, 3, 4, 5
Maximum polyphony (notes)	128
Bluetooth version	4.0
USB connector type	USB Type-A, USB Type-B
Headphone connectivity	3.5 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (min)	3 W
Built-in display	No
Country of origin	Malaysia
Tuning frequency	415.3 - 466.2 Hz
Demo songs quantity	30
Transposition range	-6 - 5 octave(s)
Sound pressure level	120 dB
Product color	White
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	284 mm
Width	1300 mm
Height	150 mm
Weight	14100 g
