MIDI Implementation
11
3. Parameter Address Map (Model ID = 42H)
This map indicates address, size, Data (range), Parameter, Description, and Default Value of parameters which can be transferred using and “Data set 1 (DT1).”
All the numbers of address, size, Data, and Default Value are indicated in 7-bits Hexadecimal-form.
9 Address Block Map
An outlined address map of the Exclusive Communication is as follows;
+------------+------------------------------------+
| Address (H)| Block |
+------------+------------------------------------+
| 40 00 00 | |
| | SYSTEM PARAMETERS | Individual
| 40 01 3F | |
+------------+------------------------------------+
+------------+------------------------------------+
| 40 1x 00 | |
| | PART PARAMETERS (x = 0–F) | Individual
| 40 2x 5A | |
+------------+------------------------------------+
+------------+------------------------------------+
| 41 m0 00 | |
| | DRUM SETUP PARAMETERS (m = 0,1) | Individual
| 41 m8 7F | |
+------------+------------------------------------+
+------------+------------------------------------+
| 48 00 00 | |
| | SYSTEM PARAMETERS | Bulk
| 48 01 0F | |
+------------+------------------------------------+
| 48 01 10 | |
| | PART PARAMETERS | Bulk
| 48 1D 0F | |
+------------+------------------------------------+
+------------+------------------------------------+
| 49 m0 00 | |
| | DRUM SETUP PARAMETERS (m = 0,1) | Bulk
| 49 mE 17 | |
+------------+------------------------------------+
There are two ways in which GS data is transmitted: Individual Parameter Transmission in which individual parameters are transmitted one by one, and Bulk Dump
Transmission in which a large amount of data is transmitted at once.
9 Individual Parameters
Individual Parameter Transmission transmits data (or requests data) for one parameter as one exclusive message (one packet of “F0 ..... F7”).
In Individual Parameter Transmission, you must use the Address and Size listed in the following “Parameter Address Map.” Addresses marked at “#” cannot be used as starting
addresses.
7System Parameters
Parameters related to the system of the device are called System Parameters.
Address (H) Size (H) Data (H) Parameter Description Default Value (H) Description
40 00 00 00 00 04 0018–07E8 MASTER TUNE -100.0–+100.0 [cent] 00 04 00 00 0 [cent]
40 00 01# Use nibblized data.
40 00 02#
40 00 03#
*Refer to section 4. Supplementary Material, “About Tuning.”
40 00 04 00 00 01 00–7F MASTER VOLUME 0–127 7F 127
(= F0 7F 7F 04 01 00 vv F7)
40 00 05 00 00 01 28–58 MASTER KEY-SHIFT -24–+24 [semitones] 40 0 [semitones]
40 00 06 00 00 01 01–7F MASTER PAN -63 (LEFT)–+63 (RIGHT) 40 0 (CENTER)
40 00 7F 00 00 01 00–7F MODE SET 00 = GS Reset,
127 = Exit GS mode
(Rx. only)
* Refer to “System Exclusive Messages Related to Mode Settings”.
40 01 10 00 00 01 00–18 VOICE RESERVE Part1 00 0
40 01 11 00 00 01 00–18 VOICE RESERVE Part2 00 0
40 01 12 00 00 01 00–18 VOICE RESERVE Part3 04 4
40 01 13 00 00 01 00–18 VOICE RESERVE Part4 18 24
40 01 14 00 00 01 00–18 VOICE RESERVE Part5 00 0
40 01 15 00 00 01 00–18 VOICE RESERVE Part6 0A 10
40 01 16 00 00 01 00–18 VOICE RESERVE Part7 00 0
40 01 17 00 00 01 00–18 VOICE RESERVE Part8 00 0
40 01 18 00 00 01 00–18 VOICE RESERVE Part9 06 6
40 01 19 00 00 01 00–18 VOICE RESERVE Part10 14 20
40 01 1A 00 00 01 00–18 VOICE RESERVE Part11 00 0
To Next Page
