6 Specications of each Speaker Type
The speaker column indicates the diameter of each speaker unit (in inches) and the
number of units.
Type Cabinet Speaker Microphone
Small 1 Small open-back enclosure 10 Dynamic
Small 2 Small open-back enclosure 10 Dynamic
Middle Open back enclosure 12 x 1 Dynamic
JC-120 Open back enclosure 12 x 2 Dynamic
Built-In 1 Open back enclosure 12 x 2 Dynamic
Built-In 2 Open back enclosure 12 x 2 Condenser
Built-In 3 Open back enclosure 12 x 2 Condenser
Built-In 4 Open back enclosure 12 x 2 Condenser
Built-In 5 Open back enclosure 12 x 2 Condenser
BG Stack 1 Sealed enclosure 12 x 2 Condenser
BG Stack 2 Large sealed enclosure 12 x 2 Condenser
MS Stack 1 Large sealed enclosure 12 x 4 Condenser
MS Stack 2 Large sealed enclosure 12 x 4 Condenser
Metal Stack Large double stack 12 x 4 Condenser
2-Stack Large double stack 12 x 4 Condenser
3-Stack Large triple stack 12 x 4 Condenser
70120: Phaser
This is a stereo phaser. A phase-shifted sound is added to the original sound and
modulated.
No Parameter Value Description
1 Mode 0–2
4-Stage,
8-Stage,
12-Stage
Number of stages in the
phaser
2 Manual #2 0–127 0–127
Adjusts the basic frequency
from which the sound will be
modulated.
3 Rate Mode 0–1 Hz, note
When this is set to “note,” the
eect is synchronized with
the tempo.
4 Rate #1 1–127
0.05–10.00
Hz
Frequency of modulation (Hz)
5 Rate 0–21 note
Frequency of modulation
(note)
6 Depth 0–127 0–127 Depth of modulation
7 Polarity 0–1
Inverse,
Synchro
Selects whether the left and
right phase of the modulation
will be the same or the
opposite.
Inverse: The left and right
phase will be opposite. When
using a mono source, this
spreads the sound.
Synchro: The left and right
phase will be the same. Select
this when inputting a stereo
source.
8 Resonance 0–127 0–127 Amount of feedback
9
Cross
Feedback
0–98 -98–+98 %
Adjusts the proportion of the
phaser sound that is fed back
into the eect. Negative (-)
settings will invert the phase.
10 Mix 0 –127 0 –127
Level of the phase-shifted
sound
11 Low Gain 0–30 -15–+15 dB Gain of the low range
12 High Gain 0–30 -15–+15 dB Gain of the high range
13 Level 0–127 0–127 Output Level
70129: Multi Stage Phaser
Extremely high settings of the phase dierence produce a deep phaser eect.
No Parameter Value Description
1 Mode 0–5
4-Stage,
8-Stage,
12-Stage,
16-Stage,
20-Stage,
24-Stage
Number of phaser stages
2 Manual #2 0–127 0–127
Adjusts the basic frequency
from which the sound will be
modulated.
3 Rate Mode 0–1 Hz, note
When this is set to “note,” the
eect is synchronized with
the tempo.
4 Rate #1 1–127
0.05–10.00
Hz
Frequency of modulation (Hz)
5 Rate 0–21 note
Frequency of modulation
(note)
6 Depth 0–127 0–127 Depth of modulation
7 Resonance 0–127 0–127 Amount of feedback
8 Mix 0 –127 0–127
Level of the phase-shifted
sound
9 Pan 0 –127 L64–63R
Stereo location of the output
sound
10 Low Gain 0–30 -15–+15 dB Gain of the low range
11 High Gain 0–30 -15–+15 dB Gain of the high range
12 Level 0–127 0–127 Output Level
7012a: Innite Phaser
A phaser that continues raising/lowering the frequency at which the sound is
modulated.
No Parameter Value Description
1 Mode 0–3 1, 2, 3, 4
Higher values will produce a
deeper phaser eect.
2 Speed #1 0 –127 -100–+100
Speed at which to raise or
lower the frequency at which
the sound is modulated
(+: upward / -: downward)
3
Resonance
#2
0–127 0–127 Amount of feedback
4 Mix 0 –127 0–127
Volume of the phase-shifted
sound
5 Pan 0 –127 L64–63R Panning of the output sound
6 Low Gain 0–30 -15–+15 dB
Amount of boost/cut for the
low-frequency range
7 High Gain 0–30 -15–+15 dB
Amount of boost/cut for the
high-frequency range
8 Level 0–127 0–127 Output volume

Roland fp-30 Specifications

General

Certification	FCC, CE
Sound effects	Ambience, Brilliance
Tones quantity	35
Pedals quantity	1
RMS rated power	24 W
Speaker diameter	120 mm
Number of speakers	2
Metronome tempo range	20 - 250 bpm
Metronome beats per bar	0, 2, 3, 4, 5
Maximum polyphony (notes)	128
Bluetooth version	4.0
USB connector type	USB Type-A, USB Type-B
Headphone connectivity	3.5 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (min)	3 W
Built-in display	No
Country of origin	Malaysia
Tuning frequency	415.3 - 466.2 Hz
Demo songs quantity	30
Transposition range	-6 - 5 octave(s)
Sound pressure level	120 dB
Product color	White
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	284 mm
Width	1300 mm
Height	150 mm
Weight	14100 g
