MIDI Implementation
26
70126: Auto Pan
Cyclically modulates the stereo location of the sound.
No Parameter Value Description
1 Mod Wave 0–4
Tri, Sqr, Sin,
Saw1, Saw2
Modulation Wave
Tri: triangle wave
Sqr: square wave
Sin: sine wave
Saw1/2: sawtooth wave
2 Rate Mode 0–1 Hz, note
When this is set to “note,”
the eect is synchronized
with the tempo.
3 Rate #1 1–127 0.05–10.00 Hz
Frequency of the change
(Hz)
4 Rate 0–21 note
Frequency of the change
(note)
5 Depth #2 0–127 0–127
Depth to which the eect
is applied
6 Low Gain 0–30 -15–+15 dB Gain of the low range
7 High Gain 0–30 -15–+15 dB Gain of the high range
8 Level 0–127 0 –127 Output Level
7012c: Slicer
By applying successive cuts to the sound, this eect turns a conventional sound
into a sound that appears to be played as a backing phrase. This is especially
eective when applied to sustain-type sounds.
No Parameter Value Description
1 Rate Mode 0–1 Hz, note
When this is set to “note,” the
eect is synchronized with
the tempo.
2 Rate 1–127
0.05–10.00
Hz
Rate at which the 16-step
sequence will cycle (Hz)
3 Rate #1 12–21 note
Rate at which the 16-step
sequence will cycle (note)
4 Attack 0 –127 0–127
Speed at which the level
changes between steps
5
Input Sync
Sw
0–1 O, On
Species whether an input
note will cause the sequence
to resume from the rst step
of the sequence (On) or not
(O)
6
Input Sync
Threshold
0–127 0–27
Volume at which an input
note will be detected
7 Mode 0–1 Legato, Slash
Sets the manner in which the
volume changes as one step
progresses to the next.
Legato: The change in volume
from one step’s level to the
next remains unaltered. If the
level of a following step is the
same as the one preceding it,
there is no change in volume.
Slash: The level is
momentarily set to 0 before
progressing to the level of the
next step. This change in
volume occurs even if the
level of the following step is
the same as the preceding
step.
8 Shue #2 0 –127 0 –127
Timing of volume changes for
even-numbered steps (step 2,
step 4, step 6...).
The higher the value, the later
the beat progresses.
9 Level 0–127 0–127 Output level
70130: Compressor
Flattens out high levels and boosts low levels, smoothing out uctuations in
volume.
No Parameter Value Description
1 Attack #2 0–127 0–127
Sets the speed at which
compression starts
2 Threshold #1 0 –127 0–127
Adjusts the volume at which
compression begins
3 Post Gain 0–18 0 – +18 dB Adjusts the output gain.
4 Low Gain 0–30 -15–+15 dB
Gain of the low frequency
range
5 High Gain 0–30 -15–+15 dB
Gain of the high frequency
range
6 Level 0–127 0–127 Output level
70131: Limiter
Compresses signals that exceed a specied volume level, preventing distortion
from occurring.
No Parameter Value Description
1 Release 0–127 0–127
Adjusts the time after the
signal volume falls below the
Threshold Level until
compression is no longer
applied.
2 Threshold #1 0 –127 0–127
Adjusts the volume at which
compression begins
3 Ratio #2 0–3
1.5:1, 2:1, 4:1,
100:1
Compression ratio
4 Post Gain 0–18 0 – +18 dB Adjusts the output gain.
5 Low Gain 0–30 -15–+15 dB
Gain of the low frequency
range
6 High Gain 0–30 -15–+15 dB
Gain of the high frequency
range
7 Level 0–127 0–127 Output level
70142: Stereo Chorus
This is a stereo chorus. A lter is provided so that you can adjust the timbre of the
chorus sound.
No Parameter Value Description
1 Filter Type 0–2 O, Lpf, Hpf
Type of lter
O: No lter is used
Lpf: Cuts the frequency range
above the Cuto Freq
Hpf: Cuts the frequency range
below the Cuto Freq
2 Cuto Freq 0–16 200–8000 Hz Basic frequency of the lter
3 Pre Delay 0–125 0.0–100.0 ms
Adjusts the delay time from
the direct sound until the
chorus sound is heard.
4 Rate Mode 0–1 Hz, note
When this is set to “note,” the
eect is synchronized with
the tempo.
5 Rate #1 1–127
0.05–10.00
Hz
Frequency of modulation (Hz)
6 Rate 0–21 note
Frequency of modulation
(note)
7 Depth #2 0–127 0–127 Depth of modulation
8 Phase 0–90 0–180 deg Spatial spread of the sound
9 Low Gain 0–30 -15–+15 dB Gain of the low range
10 High Gain 0–30 -15–+15 dB Gain of the high range
11 Balance 0 –100
D100:0W–
D0:100W
Volume balance between the
direct sound (D) and the
chorus sound (W)
12 Level 0–127 0–127 Output Level

Roland fp-30 Specifications

General

Certification	FCC, CE
Sound effects	Ambience, Brilliance
Tones quantity	35
Pedals quantity	1
RMS rated power	24 W
Speaker diameter	120 mm
Number of speakers	2
Metronome tempo range	20 - 250 bpm
Metronome beats per bar	0, 2, 3, 4, 5
Maximum polyphony (notes)	128
Bluetooth version	4.0
USB connector type	USB Type-A, USB Type-B
Headphone connectivity	3.5 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (min)	3 W
Built-in display	No
Country of origin	Malaysia
Tuning frequency	415.3 - 466.2 Hz
Demo songs quantity	30
Transposition range	-6 - 5 octave(s)
Sound pressure level	120 dB
Product color	White
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	284 mm
Width	1300 mm
Height	150 mm
Weight	14100 g
