Roland fp-30 Midi Implementation

MIDI Implementation
37
6. Tone List
Note No. Name MSB LSB PC
PIANO
A0 (21) Grand Piano 1 0 68 1
A#0 (22) Grand Piano 2 16 67 1
B0 (23) Grand Piano 3 8 66 2
C1 (24) Ragtime Piano 0 64 4
C#1 (25) Harpsichord 1 0 66 7
D1 (26) Harpsichord 2 8 66 7
E. PIANO
A0 (21) E. Piano 1 16 67 5
A#0 (22) E. Piano 2 0 70 6
B0 (23) E. Piano 3 24 65 5
C1 (24) Clav. 0 67 8
C#1 (25) Vibraphone 0 0 12
D1 (26) Celesta 0 0 9
D#1 (27) Synth Bell 0 68 99
OTHER
A0 (21) Strings 1 0 71 50
A#0 (22) Strings 2 0 64 49
B0 (23) Harp 0 68 47
C1 (24) Jazz Organ 1 0 70 19
C#1 (25) Jazz Organ 2 0 69 19
D1 (26) Church Organ 1 0 66 20
D#1 (27) Church Organ 2 8 69 20
E1 (28) Accordion 0 68 22
F1 (29) Choir 1 8 64 53
F#1 (30) Jazz Scat 0 65 55
G1 (31) Choir 2 8 66 53
G#1 (32) Choir 3 8 68 53
A1 (33) Synth Pad 0 64 90
A#1 (34) Nylon-str.Gt 0 0 25
B1 (35) Steel-str.Gt 0 0 26
C2 (36) Decay Strings 1 65 50
C#2 (37) Decay Choir 1 64 53
D2 (38) Decay Choir Pad 1 66 90
D#2 (39) Acoustic Bass 0 0 33
E2 (40) A.Bass + Cymbl 0 66 33
F2 (41) Fingered Bass 0 0 34
F#2 (42) Thum Voice 0 66 54

Roland fp-30 Specifications

General

Certification	FCC, CE
Sound effects	Ambience, Brilliance
Tones quantity	35
Pedals quantity	1
RMS rated power	24 W
Speaker diameter	120 mm
Number of speakers	2
Metronome tempo range	20 - 250 bpm
Metronome beats per bar	0, 2, 3, 4, 5
Maximum polyphony (notes)	128
Bluetooth version	4.0
USB connector type	USB Type-A, USB Type-B
Headphone connectivity	3.5 mm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Power consumption (min)	3 W
Built-in display	No
Country of origin	Malaysia
Tuning frequency	415.3 - 466.2 Hz
Demo songs quantity	30
Transposition range	-6 - 5 octave(s)
Sound pressure level	120 dB
Product color	White
Keys quantity	88 keys
Number of keyboard sensitivity levels	5

Weight and Dimensions

Depth	284 mm
Width	1300 mm
Height	150 mm
Weight	14100 g
