Roland GC-408 Service Notes

GC-408S PARTS LIST
SAFETY PRECAUTIONS:*2
The parts marked have
safety-related characteristics.
Use only listed parts for
replacement.
!
CONSIDERATIONS ON PARTS ORDERING
When ordering any parts listed in the parts list, please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or
even undelivered replacement.
12
NOTE1:The parts marked # are new.
NOTE2:The parts marked # have safety-related characteristics.
Use only listed parts for replacement.
CABINET
# SS000140 CABINET ASSY GC-408S 52114000000
NOTE1:Replacement CABINET ASSY includes the following parts
# SS000160 RUBBER FOOT RF-02 60381030001
SS000070 CORNER CSN-03 60420220001
SS000076 HANDLE HDBK-02 60513110001
SS000077 HANDLE BRAKET HBNI-02 60523020001
SS000156 RUBBER SHEET 60331510000
# SS000111 BAFFLE BOARD ASSY GC-408S
NOTE2:Replacement BAFFLE BOARD ASSY includes the following parts.
# SS000161 LOGO ROLAND(LARGE) 60391310101
SS000167 ANGLE BRACKET 90120100000
SS000109 BACK BOARD ASSY
NOTE3:Replacement BACK BOARD includes the following parts.
# SS000168 BACK PLATE 90140000001 For BACK BOARD
JACK
SS000115 PHONE JACK MONO 12.5M/M JK10
SPEAKER
# SS000135 SPEAKER GC-408/S 40160908034
WIRING,CABLE
# SS000183 SPEAKER WIRE (BLK)
# SS000196 SPEAKER SYSTEM WIRE (WHT)
# SS000197 SPEAKER SYSTEM WIRE (BLK)
# SS000198 SPEAKER WIRE (WHT)
SCREW
SS000050 TAPPING SCREW NI TH1 3.5x12 60000001402 For CORNER
SS000171 TAPPING SCREW BK FH1 2.6x10 60000000202 For LOGO
SS000144 TAPPING SCREW BK TH1 3.5x10 60000000401 For BACK PLATE
SS000047 TAPPING SCREW BK TH1 3.5x15 60000000404 For WIRE CLAMP
# SS000145 TAPPING SCREW BK TH1 3.5x18 60000000405 For RUBBER FOOT
# SS000049 TAPPING SCREW BK 0H1 3.5X45 60000000410 For CABINET SIDE
# SS000146 TAPPING SCREW BK TH1 3.5x35 60000000411 For BACK BOARD
# SS000152 TAPPING SCREW NI FH1 3.5x15 60052501521 For ANGLE BRACKET
# SS000147 MACHINE SCREW BK TH M4x20 60000000503 For SPEAKER
SS000051 MACHINE SCREW NI OH M4x32 60000001507 For HANDLE BRACKET
SS000054 WASHER BK NAVEL 4 FAI 60000009010 For CABINET TOP & SIDE
SS000055 NUT BK ABS JACK 60000009062 For PHONE JACK
# SS000149 BK T NUT M4 60000009090 For CABINET BAFFLE BOARD
PACKING CASE
# SS000143 OUTER PACKING 55114000000
MISCELLANEOUS
# SS000156 RUBBER SHEET 60331510000 For BAFFLE BOARD
ACCESSORIES(Standard)
# SS000105 OWNER'S MAMUAL ENGLISH
# SS000106 OWNER'S MANUAL JAPANESE
# SS000155 EXT S/P CABLE GC-408S 60207004082
!
Dec, 1997
GC-408/GC-408S
