Roland GC-408 Service Notes

2
LOCATION OF CONTROLS
Dec, 1997
GC-408/GC-408S
[PARTS]
No. Part Cord Part Name
q SS000115 PHONE JACK MONO 12.5M/M
SS000055 NUT BK ABS JACK
w SS000065 BUTTON PNBB-18
SS000020 PUSH SWITCH JDPA-21SA
e~i SS000066 KNOB CNBB-09
e SS000011 POTENTIOMETER A50k V/R 16F
r SS000013 POTENTIOMETER B250k V/R 16F
t SS000012 POTENTIOMETER B20k V/R 16F
y SS000126 POTENTIOMETER A500k V/R 16F
u SS000127 POTENTIOMETER B10k V/R 16F
i SS000015 POTENTIOMETER C10k V/R 16F
o SS000132 POWER SWITCH H8660VB
!0 SS000021 AC SWITCH H8653VB
!1 SS000123 LED KLG124
!2 SS000122 LED KLR124
!3 SS000141 PANEL (FRONT/REAR)
GC-408 [FRONT VIEW]
GC-408 [REAR VIEW]
