12
Mar. 2006 HPD-10
ENCODER
03231912 ROTARY ENCODER W/SW R-ENCODER EVQB1SZ1720B EN1 on PANEL 1
CONNECTOR
13369664 CONNECTOR S4B-PH-K-S(LF/SN)(4P) CN3 on MAIN 1
02012056 CONNECTOR CONNECTOR 28FMN-BTK-A CN5, 6 on MAIN 2
02564678 CONNECTOR 12FE-ST-VK-N CN4 on MAIN 1
WIRING, CABLE
# 04129578 BAN CARD BNCD-P=1.25-K-12-240 1
03671856 BAN CARD BNCD-P=1.00-K-28-60 2
PICK UP, SENSOR
# 73129534 PIEZO ASSY 1
01900245 PRESSURE SHEET SENSOR 1
SCREWS
40238145 SCREW M5X12 TRUSS BZC 4
40340812 SCREW M3X10 PAN MACHINE W/SW BZC 4
02126156 SCREW M3X10 HEX SOCKET HEAD CAP TAPTITE P 10
40011278 SCREW 3X8 BINDING TAPTITE P FE ZC 22
40011245 SCREW 4X12 BINDING P-TITE FE NI 18
PACKING
# 04234890 LOWER PAD 1
# 04234923 OUTER PACKING CASE 5
# 04234878 PACKING CASE 1
# 04234889 UPPER PAD 1
MISCELLANEOUS
12199584 GROUNDING TERMINAL M1698 TER1, TER2, TER3 on MAIN 3
12169368 LED SPACER LDS-40B 2
! 02567234 LITHIUM BATTERY CR2032 1
02567267 BATRY HOLDER BCR20H4 BH1 on MAIN 1
22365714 CORD HOOK 1
# 04234912 ACCESSORY CASE 1
01900234 CUSHION 1
# 73237490 FOOT ASSY 1
# 40673845 LOGO LABEL S 2
# 40673812 CAUTION LABEL S 1
ACCESSORIES (Standard)
#
04129623 OWNER’S MANUAL JAPANESE 1
# 04129645 OWNER’S MANUAL ENGLISH 1
40232334 WARRANTY CARD MOCHIKOMI JAPAN ONLY 1
! 00905756 AC ADAPTOR ACI-100C for 100V 1
! 00905767 AC ADAPTOR ACI-120C for 117V U, 117V U/CS 1
! 03017356 AC ADAPTOR WITHOUT AC
CORD
PSB-1U(R) UNIVERSAL for 230V E, 240V A 1
01903356 AC CORD SET 230V 1.0M FOR PSB for 230V E 1
00905234 EURO CONVERTER PLUG ECP01-5A for 230V E 1
! 01018312 AC ADAPTOR ACI-230C for 230V EU 1
03785590 AC CORD SET SC-078-NA05 240VA for 240V A 1
ETC
40231345 BOND KONISHI BOND CYEREX100 330ML
40236878 KONISHI CYEREX 100 120ML
40232123 ACETATE TAPE NITTO #5 BLACK W20MM 30M 2P
Service Notes(A4)_e 12 ページ ２００６年６月１日 木曜日 午後４時５分
