Roland HandSonic 10 - Location of Controls Parts List

5
Mar. 2006 HPD-10
Location of Controls Parts List
No
PART CODE PART NAME DESCRIPTION Q’TY
1 # 04129545 TOP PANEL 1
2 # 04129589 RUBBER SW 1
3 03565789 M R-KNOB LF-ELA BLK 1
4 03125589 M R-KNOB MF-ELA BLK/LCG 1
5 # 73129523 PANEL BOARD ASSY includes the LCD 1
6 # 04129445 ESCUTCHEON D-BEAM CONTROLLER 1
7 03126134 LED(INFRARED) TLN233(F) 1
8 01900612 DIODE TPS611(F) 1
9 # 04124990 PLAYING PLATE 1
10 # 04129556 REAR PANEL 1
11 22365714 CORD HOOK 1
12 12499175 BUTTON JSPUE0011A 1
13 13449711 AC ADAPTOR JACK HEC0470-01-630 1
14 02892878 DIN(MIDI) JACK 2DJ-00600003 2
15 00569278 6.5MM JACK LGR4609-7100F 5
