3
USB port
USB Computer port
If you use a commercially available
USB cable to connect the KF-10’s USB
COMPUTER port to your computer’s USB
port, you’ll be able to do the following
things.
5 SMF data played back by MIDI-
compatible software can be sounded
by the KF-10.
5 MIDI data can be transferred between the KF-10 and your DAW
software, opening up a wide range of possibilities for music
production and editing.
USB Memory port
Connect a USB ash drive here.
5 If a USB ash drive is connected, you can play
songs.
* Never turn o the power or remove the USB ash
drive and Power cord while the USB ash drive is
blinking.
* Carefully insert the USB ash drive all the way in—
until it is rmly in place.
Phones jacks
You can connect headphones here.
Bottom Panel
Headphones
* To prevent malfunction and equipment failure, always turn
down the volume, and turn o all the units before making any
connections.
DC In jack
Connect the included AC adaptor here.
Pedal jack
Connect the included pedal.
Damper Pedal (right pedal)
Use this pedal to sustain the sound.
While this pedal is held down, notes
will be sustained for an extended time
even if you release your ngers from the
keyboard.
You can also adjust the amount of
resonance by varying the depth to which
you press the pedal.
Sostenuto Pedal (center pedal)
The notes you are pressing when this pedal is depressed will be sustained.
Soft Pedal (left pedal)
This pedal is used to make the sound softer. Playing with the soft pedal depressed
produces a sound that is not as strong as when otherwise played with the
equivalent strength. The softness of the tone can be varied subtly by the depth to
which you press the pedal.
Rear Panel
Power Cord
AC Outlet
Place the AC adaptor so the side with the indicator (see
illustration) faces upwards and the side with textual information
faces downwards. The indicator will light when you plug the AC
adaptor into an AC outlet.
