MIDI Implementation
A-70
MV-8800 Appendices
● Song Position Pointer
mm, ll=value: 00, 00H - 7F, 7FH (0 - 16383)
* Received when Sync Mode parameter (SYNC or PATTERN SYNC screen) is set to
Slave-MIDI.
■ System Realtime Messages
* Received when Sync Mode parameter (SYNC or PATTERN SYNC screen) is set to
Slave-MIDI or Remote.
● Timing Clock
● Start
● Continue
● Stop
■ System Exclusive Message
● MIDI Time Code
❍ Full Message
Byte
Description
F0H Status of System Exclusive Message
7FH Universal System Exclusive Real-time Header
Dev Device ID (or 7FH)
01H MIDI Time Code
01H MIDI Time Code Full Message
hr Type/Hour (0yyzzzzz)
yy: Time Code Type
0=24 Frame/Sec
1=25 Frame/Sec
2=30 Frame/Sec (Drop)
3=30 Frame/Sec (Non-Drop)
zzzzz: Hours (0-23)
mn Minutes (0-59)
sc Seconds (0-59)
fr Frames (0-59)
F7H EOX (End of System Exclusive message)
* Received when the Sync Mode parameter (SYNC or PATTERN SYNC screen) is set to
Slave-MTC.
● MIDI Machine Control (MMC)
* Received when the MMC Mode parameter (SYNC or PATTERN SYNC screen) is Slave.
❍ STOP (MCS)
Byte Remarks
F0H Exclusive status
7FH Universal System Exclusive Realtime Header
dev Device ID (or 7FH)
06H MMC command message
01H STOP (MCS)
F7H EOX (End of Exclusive)
❍ PLAY (MCS)
Byte
Remarks
F0H Exclusive status
7FH Universal System Exclusive Realtime Header
dev Device ID (or 7FH)
06H MMC Command Message
02H PLAY (MCS)
F7H EOX (End of System Exclusive message)
❍ DEFERRED PLAY (MCS)
Byte
Remarks
F0H Exclusive status
7FH Universal System Exclusive Realtime Header
dev Device ID (or 7FH)
06H MMC command message
03H DEFERRED PLAY (MCS)
F7H EOX (End of Exclusive)
Status
2nd byte 3rd byte
F2H
llH mmH
Status
F8H
Status
FAH
Status
FBH
Status
FCH
Status
Data byte Status
F0H
7EH, dev, 01H, 01H, hrH, mnH, scH, frH
F7H
Status
Data byte Status
F0H
7FH, dev, 06H, 01H F7H
Status
Data byte Status
F0H 7FH, dev, 06H, 02H F7H
Status
Data byte Status
F0H
7FH, dev, 06H, 03H F7H
