19
Receiving Remote Control from Other Devices
The R-1000 supports remote control from a device connected to the MIDI connector. You can remote control from a MIDI device
like electronic musical instruments or MIDI sequencers. The MIDI messages below can be sent/received.
fig.MIDI-message.eps
Set device ID and MIDI OUT/THRU of connector
If you are remote controlling from a MIDI device, set the MIDI device ID and function of MIDI OUT/THURU connector as shown
below.
1. Open the menu
Press [MENU] button to open the menu.
2. Select the remote control menu
Select the [SYSTEM] menu and then select [REMOTE CONTROL]. The setup screen for remote control opens up.
3. Select a device ID
Select [DEVICE ID] in MIDI and select an ID for the R-1000 from 1 through 32.
4. Set function for MIDI OUT/THRU connector
Go back to the previous setup screen and select [MIDI OUT/THRU]. Select the function from below.
fig.MIDI-type.eps
The R-1000 supports remote control from a computer connected to the front panel USB-PC connector. You can send the
messages shown below.
fig.USB-MIDI-message.eps
If you are using a computer as USB MIDI device, you must install the V-Mixer driver to your computer. Download the driver from the Roland
website.
http://www.rolandsystemsgroup.net/
You can also remotely control the R-1000 from the dedicated remote control software “R-1000 RCS”. You can download it from the Roland
website as below.
http://www.rolandsystemsgroup.net/
Set device ID
If you are remote controlling from USB MIDI device, set the MIDI device ID as shown below.
1. Open the menu
Press [MENU] button to open the menu.
2. Select the remote control menu
Select the [SYSTEM] menu and then select [REMOTE CONTROL]. The setup screen for remote control opens up.
3. Select a device ID
Select [DEVICE ID] in MIDI and select an ID for the R-1000 from 1 through 32.
Receiving Remote Control from MIDI devices
Receiving Remote Control from USB MIDI devices
MMC
MTC
REC/PLAY control
Time info during REC/PLAY
OUT
THRU
Use as MIDI OUT connector.
Use as MDI THRU connector.
Time information during play/rec (send only)
System Exclusive Parameter Control
MTC
