4
Use in Connection with the V-Mixer
Remote control setup on the R-1000
To remotely control the R-1000 in the scenario shown above, make the following settings in your R-1000.
Parameter Value
• REAC SETUP REC ONLY
• MTC OUTPUT ON
• MIDI OUT/THRU OUT
* For details about the various parameters, refer to "Menu Operations and Menu List" in the R-1000 Owner's Manual.
Remote control setup on the V-Mixer
If you're using the V-Mixer to control the R-1000 as shown above, use the following settings.
Parameter Value
• REAC SETUP FOH
• MIDI OUT/THRU OUT
• RECEIVE Sys Ex ON
• SEND Sys Ex ON
• CONTROL TARGET MIDI
* For details about the various parameters, refer to the V-Mixer's Owner's Manual.
REAC mode setup on the Digital Snake units
Set REAC mode to [SLAVE].
Remote controlling the recording
Open the popup screen on the V-Mixer to remotely control the R-1000.
Track settings
Open the recording patchbay of the R-1000 from the V-Mixer. Assign input 1 through 40 coming in from REAC port A on the R-
1000 to recording tracks 1 through 40. In this configuration, the R-1000 will be recording the 40 sources that are assigned in the V-
Mixer's REAC A Output patchbay. These outputs will become inputs to the R-1000's tracks. NOTE: Because the R-1000 is being
used as a Split location, it will not be able to play tracks back into the V-Mixing system; it will record only.
* It is easy to assign these channels using the auto map function. Use [F-7] of the V-Mixer’s function button to call up the auto map function.
fig.patchbay-case1.eps
Start recording on the R-1000
Arm/Select the recording tracks of the R-1000 from the V-Mixer and start recording.
fig.R1000-coontrol-popup1.eps
To Next Page
