RD-100
Feb, 1999
6
7699408000 7P CABLE ASSY (38) 2C P.2 From CN4 on MB to CN1 on JB
7697239001 7P CABLE ASSY (16) 2C P 2.5 D/R From CN2 on Switching B. to CN3 on JB
7700115000 8P CABLE ASSY (40) 2C P.2 From CN5 on CB to CN4 on JB
7699413000 10P CABLE ASSY (12) 2C P.2 From CN7 on MB to CN5 on JB
7699418000 10P CABLE ASSY (38) 2C P.2 From CN5 on MB to CN4 on JB
K3468178 20P FLAT CABLE (44) 2C/D From CN2 on MB to CN1 on RCB
K3468185 20P CABLE ASSY (24) 2C From CN1 on MB to CN1 on LCB
AC INLET
J3449103 UNIVERSAL AC INLET
SCREW
J2289102 SELF TAP.SCREW 2.9X10 TC TC
J2289108 SELF LOCK.SCREW M3X10 TCTC H.6
J2289113 NUT 3MA H.3
J2289186 SCREW 3.5X16 TCPR TFR H.8 BRUN
J2289193 SELF LOCK.SCREW M3X6 TC TC H.6
J2289202 SELF TAP.SCREW 2.9X16 C C
J2289213 SELF TAP.SCREW 3.9X16 TC TC
# J2289221 SELF LOCK.SCREW M4X10 TC TC TFR 9.5
# J2289222 NUT 10MA TH.8
PACKING
# K2638211 RIGHT LDPE PROTECTION RD-100
# K2638212 LEFT LDPE PROTECTION RD-100
# K2638213 CENTRAL LDPE PROTECTION RD-100
# K2638214 LDPE PROTECTION F/PEDAL RD-100
K2678119 CARTENE ENVELOPE HD CM.170X56
# K2618207 OUTER PACKING RD-100
MISCELLANEOUS
J2139119 MYLAR WASHER E.D.8 I.D.4
K2168102 SPACER FOR LED H.2.8 D.E. 5.5
K2168109 SPACER FOR LED H.10 - D.E. 5.5
K2168112 LED SPACER H. 4.5 MAX 9 MM
J2359105 PRESSURE RUBBER SFF-018
K2268121 RED FELT MM 1250X12X1.5
K2248129 ANTIDUST COVER PL30N
K2268148 ADHESIVE BLACK FELT 25X1X1240
# K253810302 FUSE WARNING LABEL
ACCESSORIES
J3439150 MAINS CABLE H05VV+POL.SOCKET (230V)
J3439128 CABLE 498/3SJT 2X18 AWG-C17 (117V)
13499152RI CABLE BS/13/H05VV-F3G0.75-V (230VE)
J3439167 MAINS CABLE SAA/2-H05VV5 2X1-C17 (240VA)
# K6018342 O.MANUAL (E/D/F/I/SP/DUTCH) RD-100
J3059103 PEDAL W/CABLE
Note : Replacement should be made on a unit basis. No replacements available for individual parts.
Replacement only be a unit.
