10
MIDI Implementation
* System V-Link
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0000 000a | Switch (0 - 1) |
| | | OFF,ON |
| 00 01 | 0000 000a | Mode (0 - 1) |
| | | BANK/PC.NOTE |
| 00 02 | 0aaa aaaa | Lowest No (0 - 127) |
| 00 03 | 0000 aaaa | Transmit Channel (0 - 15) |
| 00 04 | 0000 0aaa | Output Port (0 - 4) |
| | | ALL, OUT1, OUT2, OUT3, USB |
| 00 05 | 0aaa aaaa | Key Range Lower (0 - 87) |
| 00 06 | 0aaa aaaa | Key Range Upper (0 - 87) |
| 00 07 | 0000 000a | Local Control (0 - 1) |
| | | OFF, ON |
|-------------+----------------------------------------------------------------|
| 00 00 00 08 | Total Size |
+------------------------------------------------------------------------------+
* SETUP Common
+------------------------------------------------------------------------------+
| Offset | |
| Address | Description |
|-------------+----------------------------------------------------------------|
| 00 00 | 0aaa aaaa | SETUP Name 1 (32 - 127) |
| | | 32 - 127 [ASCII] |
| 00 01 | 0aaa aaaa | SETUP Name 2 (32 - 127) |
| 00 02 | 0aaa aaaa | SETUP Name 3 (32 - 127) |
| 00 03 | 0aaa aaaa | SETUP Name 4 (32 - 127) |
| 00 04 | 0aaa aaaa | SETUP Name 5 (32 - 127) |
| 00 05 | 0aaa aaaa | SETUP Name 6 (32 - 127) |
| 00 06 | 0aaa aaaa | SETUP Name 7 (32 - 127) |
| 00 07 | 0aaa aaaa | SETUP Name 8 (32 - 127) |
| 00 08 | 0aaa aaaa | SETUP Name 9 (32 - 127) |
| 00 09 | 0aaa aaaa | SETUP Name 10 (32 - 127) |
| 00 0A | 0aaa aaaa | SETUP Name 11 (32 - 127) |
| 00 0B | 0aaa aaaa | SETUP Name 12 (32 - 127) |
|-------------+-----------+----------------------------------------------------|
| 00 0C | 0aaa aaaa | Voice Reserve 1 (0 - 64) |
| | | 0 - 63, FULL |
| 00 0D | 0aaa aaaa | Voice Reserve 2 (0 - 64) |
| 00 0E | 0aaa aaaa | Voice Reserve 3 (0 - 64) |
| 00 0F | 0aaa aaaa | Voice Reserve 4 (0 - 64) |
| 00 10 | 0aaa aaaa | Voice Reserve 5 (0 - 64) |
| 00 11 | 0aaa aaaa | Voice Reserve 6 (0 - 64) |
| 00 12 | 0aaa aaaa | Voice Reserve 7 (0 - 64) |
| 00 13 | 0aaa aaaa | Voice Reserve 8 (0 - 64) |
| 00 14 | 0aaa aaaa | Voice Reserve 9 (0 - 64) |
| 00 15 | 0aaa aaaa | Voice Reserve 10 (0 - 64) |
| 00 16 | 0aaa aaaa | Voice Reserve 11 (0 - 64) |
| 00 17 | 0aaa aaaa | Voice Reserve 12 (0 - 64) |
| 00 18 | 0aaa aaaa | Voice Reserve 13 (0 - 64) |
| 00 19 | 0aaa aaaa | Voice Reserve 14 (0 - 64) |
| 00 1A | 0aaa aaaa | Voice Reserve 15 (0 - 64) |
| 00 1B | 0aaa aaaa | Voice Reserve 16 (0 - 64) |
|-------------+-----------+----------------------------------------------------|
|# 00 1C | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | SETUP Tempo (10 - 500) |
|-------------+-----------+----------------------------------------------------|
|# 00 1F | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Upper [Piano] Tone Category (0 - 511) |
|# 00 22 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Upper [E.Piano] Tone Category (0 - 511) |
|# 00 25 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Upper [CLAV/MALLET] Tone Category (0 - 511) |
|# 00 28 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Upper [ORGAN] Tone Category (0 - 511) |
|# 00 2B | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Upper [STRINGS] Tone Category (0 - 511) |
|# 00 2E | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Upper [PAD] Tone Category (0 - 511) |
|# 00 31 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Upper [GUITAR/BASS] Tone Category (0 - 511) |
|# 00 34 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Upper [BRASS/WINDS] Tone Category (0 - 511) |
|# 00 37 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Upper [VOICE/SYNTH] Tone Category (0 - 511) |
|# 00 3A | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Upper [RHY/GM2] Tone Category (0 - 511) |
|-------------+-----------+----------------------------------------------------|
|# 00 5B | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Lower [Piano] Tone Category (0 - 511) |
|# 00 5E | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Lower [E.Piano] Tone Category (0 - 511) |
|# 00 61 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Lower [CLAV/MALLET] Tone Category (0 - 511) |
|# 00 64 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Lower [ORGAN] Tone Category (0 - 511) |
|# 00 67 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Lower [STRINGS] Tone Category (0 - 511) |
|# 00 6A | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Lower [PAD] Tone Category (0 - 511) |
|# 00 6D | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Lower [GUITAR/BASS] Tone Category (0 - 511) |
|# 00 70 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Lower [BRASS/WINDS] Tone Category (0 - 511) |
|# 00 73 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Lower [VOICE/SYNTH] Tone Category (0 - 511) |
|# 00 76 | 0000 000a | |
| | 0000 bbbb | |
| | 0000 cccc | Lower [RHY/GM2] Tone Category (0 - 511) |
|-------------+-----------+----------------------------------------------------|
| 01 17 | 0aaa aaaa | FC 1 Assign (0 - 109) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND-UP, BEND-DOWN, AFTERTOUCH, |
| | | OCT-UP, OCT-DOWN, START/STOP, |
| | | TAP-TEMPO, RHY PLY/STP, ARPEGGIO SW, |
| | | AUDIOKEY ON/OFF,SNG PLY/STP, |
| | | MFX1 ON/OFF, MFX2 ON/OFF, |
| | | MFX1 CONTROL, MFX2 CONTROL |
| 01 18 | 0aaa aaaa | FC 2 Assign (0 - 109) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND-UP, BEND-DOWN, AFTERTOUCH, |
| | | OCT-UP, OCT-DOWN, START/STOP, |
| | | TAP-TEMPO, RHY PLY/STP, ARPEGGIO SW, |
| | | AUDIOKEY ON/OFF,SNG PLY/STP, |
| | | MFX1 ON/OFF, MFX2 ON/OFF, |
| | | MFX1 CONTROL, MFX2 CONTROL |
|-------------+-----------+----------------------------------------------------|
| 01 19 | 0000 00aa | MFX Knob1 Assgin (0 - 2) |
| | | OFF, MFX1, TEMPO |
| 01 1A | 0000 00aa | MFX Knob2 Assgin (0 - 2) |
| | | OFF, MFX2, TEMPO, |
| 01 1B | 0000 aaaa | S1 Assign (0 - 11) |
| | | OFF, COUPLE+1OCT, COUPLE-1OCT, |
| | | COUPLE+2OCT, COUPLE-2OCT, |
| | | COUPLE+5TH, COUPLE-4TH, |
| | | OCT-UP, OCT-DOWN, START/STOP, |
| | | TAP-TEMPO, SNG PLY/STP |
| 01 1C | 0000 aaaa | S2 Assign (0 - 11) |
| | | OFF, COUPLE+1OCT, COUPLE-1OCT, |
| | | COUPLE+2OCT, COUPLE-2OCT, |
| | | COUPLE+5TH, COUPLE-4TH, |
| | | OCT-UP, OCT-DOWN, START/STOP, |
| | | TAP-TEMPO, SNG PLY/STP |
| 01 1D | 0000 000a | S1 State (0 - 1) |
| | | OFF, ON |
| 01 1E | 0000 000a | S2 State (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 01 1F | 0000 000a | EQ Switch (0 - 1) |
| | | OFF, ON |
| 01 20 | 000a aaaa | EQ Input Gain (0 - 30) |
| | | -15 - +15[dB] |
| 01 21 | 0000 000a | EQ Low Type (0 - 1) |
| | | Shelving, Peaking |
| 01 22 | 000a aaaa | EQ Low Frequency (0 - 30) |
| | | 16,20,25,31,40,50,63,80,100,125,160, |
| | | 200.250,315,400,500,630,800,1000, |
| | | 1250,1600,2000,2500,3150,4000,5000, |
| | | 6300,8000,10000,12500,16000,[Hz] |
| 01 23 | 0aaa aaaa | EQ Low Gain (4 - 124) |
| | | -12.0 - +12.0[dB] (1step = 0.2dB) |
| 01 24 | 0000 0aaa | EQ Low Q (0 - 4) |
| | | 0.5, 1.0, 2.0, 4.0, 8.0 |
| 01 25 | 000a aaaa | EQ Mid Frequency (0 - 30) |
| | | 16,20,25,31,40,50,63,80,100,125,160, |
| | | 200.250,315,400,500,630,800,1000, |
| | | 1250,1600,2000,2500,3150,4000,5000, |
| | | 6300,8000,10000,12500,16000,[Hz] |
| 01 26 | 0aaa aaaa | EQ Mid Gain (4 - 124) |
| | | -12.0 - +12.0[dB] (1step = 0.2dB) |
| 01 27 | 0000 0aaa | EQ Mid Q (0 - 4) |
| | | 0.5, 1.0, 2.0, 4.0, 8.0 |
| 01 28 | 000a aaaa | EQ Mid Frequency (0 - 30) |
| | | 16,20,25,31,40,50,63,80,100,125,160, |
| | | 200.250,315,400,500,630,800,1000, |
| | | 1250,1600,2000,2500,3150,4000,5000, |
| | | 6300,8000,10000,12500,16000,[Hz] |
| 01 29 | 0aaa aaaa | EQ Mid Gain (4 - 124) |
| | | -12.0 - +12.0[dB] (1step = 0.2dB) |
| 01 2A | 0000 0aaa | EQ Mid Q (0 - 4) |
| | | 0.5, 1.0, 2.0, 4.0, 8.0 |
| 01 2B | 0000 000a | EQ High Type (0 - 1) |
| | | Shelving, Peaking |
| 01 2C | 000a aaaa | EQ High Frequency (0 - 30) |
| | | 16,20,25,31,40,50,63,80,100,125,160, |
| | | 200.250,315,400,500,630,800,1000, |
| | | 1250,1600,2000,2500,3150,4000,5000, |
| | | 6300,8000,10000,12500,16000,[Hz] |
| 01 2D | 0aaa aaaa | EQ High Gain (4 - 124) |
| | | -12.0 - +12.0[dB] (1step = 0.2dB) |
| 01 2E | 0000 0aaa | EQ High Q (0 - 4) |
| | | 0.5, 1.0, 2.0, 4.0, 8.0 |
|-------------+-----------+----------------------------------------------------|
| 01 2F | 0aaa aaaa | Key Touch Velocity (0 - 127) |
| | | REAL, 1 - 127 |
| 01 30 | 0000 0aaa | Key Touch Curve Type (1 - 5) |
| | | SUPER LIGHT, LIGHT, |
| | | MEDIUM, HEAVY, SUPER HEAVY |
| 01 31 | 000a aaaa | Key Touch Curve offset (54 - 73) |
| | | -10 - +9 |
| 01 32 | 0aaa aaaa | Key Touch Velocity Delay Sens (1 - 127) |
| | | -63 - +63 |
| 01 33 | 0aaa aaaa | Key Touch Velocity Key Follow (1 - 127) |
| | | -63 - +63 |
| 01 34 | 0000 000a | Key Touch Mode (0 - 1) |
| | | MODE1, MODE2 |
|-------------+-----------+----------------------------------------------------|
| 01 35 | 0000 000a | Slider Select (0 - 1) |
| | | ZONE LEVEL, CONTROL |
| 01 36 | 0aaa aaaa | Slider Assign (UPPER1) (0 - 97) |
| | | OFF, CC01 - CC31, CC33 - CC95, |
| | | BEND-UP, BEND-DOWN, AFTERTOUCH, |
| 01 37 | 0aaa aaaa | Slider Assign (UPPER2) (0 - 97) |
| 01 38 | 0aaa aaaa | Slider Assign (LOWER1) (0 - 97) |
| 01 39 | 0aaa aaaa | Slider Assign (LOWER2) (0 - 97) |
|-------------+-----------+----------------------------------------------------|
| 01 3B | 0000 000a | Split Switch (Internal) (0 - 1) |
| | | OFF, ON |
| 01 3C | 0000 000a | Split Switch (External) (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 01 3D | 0000 00aa | MFX Source (0 - 3) |
| | | UPPER1,UPPER2,LOWER1,LOWER2 |
| 01 3E | 0000 00aa | MFX Destination (0 - 2) |
| | | NORMAL, SAME MFX PART, ALL PART |
|-------------+-----------+----------------------------------------------------|
| 01 3F | 0000 000a | Reverb Switch (0 - 1) |
| | | OFF, ON |
| 01 40 | 0000 000a | Chorus Switch (0 - 1) |
| | | OFF, ON |
|-------------+-----------+----------------------------------------------------|
| 01 41 | 0000 aaaa | Harmonic Bar Assign (LOWER2:ON) (1 - 9) |
| | | 16',5-1/3',8',4',2-2/3',1-3/5',2',1-1/3',1' |
| 01 42 | 0000 aaaa | Harmonic Bar Assign (LOWER2:OFF) (1 - 9) |
| 01 43 | 0000 aaaa | Harmonic Bar Assign (LOWER1:ON) (1 - 9) |
| 01 44 | 0000 aaaa | Harmonic Bar Assign (LOWER1:OFF) (1 - 9) |
| 01 45 | 0000 aaaa | Harmonic Bar Assign (UPPER2:ON) (1 - 9) |
| 01 46 | 0000 aaaa | Harmonic Bar Assign (UPPER2:OFF) (1 - 9) |
| 01 47 | 0000 aaaa | Harmonic Bar Assign (UPPER1:ON) (1 - 9) |
| 01 48 | 0000 aaaa | Harmonic Bar Assign (UPPER1:OFF) (1 - 9) |
|-------------+-----------+----------------------------------------------------|
| 01 49 | 0000 000a | V-Link Switch (0 - 1) |
| | | OFF,ON |
|-------------+-----------+----------------------------------------------------|
| 01 4A | 0000 00aa | Current Control Zone (0 - 3) |
| | | UPPER1,UPPER2,LOWER1,LOWER2 |
|-------------+----------------------------------------------------------------|
| 00 00 01 4D | Total Size |
+------------------------------------------------------------------------------+
