Roland RD-88 Install Manual

3
SOUND PACK/WAVE EXPANSION Install Manual
02
Initializing the User Licenses
If you’ve initialized the user licenses, you’ll be able to import or
install SOUND PACK and WAVE EXPANSION that you downloaded
using a new user license.
NOTE
5
Installed WAVE EXPANSION are deleted.
5
EXZ001 is not deleted even if you perform this operation.
5
Never turn off the power or disconnect the USB flash drive
during a process, such as while the “Processing…” display is
shown.
1. Press the [MENU] button.
2. Use the cursor [ ] [ ] buttons to select “UTILITY,” and
then press the [ENTER] button.
3. Use the cursor [ ] [ ] buttons to select “FACTORY RESET,”
and then press the [ENTER] button.
If sound packs or wave expansions were imported or installed,
an item selection screen appears.
4. Use the cursor [ ] [ ] buttons to select “Remove License,”
and press the [ENTER] button to add a check mark in the
check box.
Pressing the [ENTER] button once again clears the check mark.
NOTE
5
If the “Reset User Data” check box is checked, all user data is
initialized. If you want to keep the user data, clear this check
box.
5
If no sound pack or wave expansion has been imported or
installed, the item selection screen does not appear; the user
data initialization confirmation screen appears. In this case,
there is no need to initialize the user license, so press the [EXIT]
button to return to the previous screen.
5. Press the cursor [>] button.
A confirmation message appears.
If you decide to cancel, press the [EXIT] button.
6. To execute, press the [ENTER] button.
When the restore operation is finished, the screen indicates
“Completed. Turn off power.”
7. Turn the power of the RD-88 off and then on again.
Error Message
Message Action
Expansion File Not
Found!
This appears if the USB flash drive does not contain
a WAVE EXPANSION file.
Check that the file is correctly saved, and that the
file extension is “.exz.”
Incorrect File!
This appears if the selected sound file is not
compatible with the RD-88, or if the file is
damaged.
Check the models that are listed as compatible
for the file you downloaded, and try downloading
again.
Incorrect License! Please
Remove License
This appears if the selected sound file is associated
with a different user license.
To install, you must either obtain a file that has the
same user license as the currently-installed sound
file, or initialize the user licenses.
Expansion Memory Full!
This appears if there is insufficient free space for
installation.
To install, you must uninstall a currently-installed to
create free space.
It has already been
installed
This appears if the selected file is already installed.
There is no need to reinstall.

Roland RD-88 Specifications

General

Tones quantity	3000
RMS rated power	6 W
Speaker diameter	120 mm
Tweeter diameter	20 mm
Number of speakers	2
Compatible memory cards	MicroSD (TransFlash)
Keys quantity	88 keys
Display resolution	128 x 64 pixels
Product color	Black
AC input voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	258 mm
Width	1284 mm
Height	159 mm
Weight	13500 g
