Contents

USING THE UNIT SAFELY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

IMPORTANT NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Panel Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Top Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Rear Panel (for Equipment Connections) . . . . . . . . . . . . . . . . . . . . . . 8

Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Turning the Power On and O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Changing the Screens Displayed on the Monitors . . . . . . . . . . . . . . 10

Using the Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Switching the Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Returning Settings to the Factory-default State (Factory Reset) . . 12

Appendices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Main Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Checking the Included Items

The following items are included with this unit. Check to make sure that all items are present. If anything is missing, contact your dealer.

 The unit AC adaptor/Power cord Owner’s Manual

* The shape of the power cord’s plug varies depending

on the country.

Getting Started

Thank you, and congratulations on your choice of the V-1200HDR Control Surface (“this unit”).

This unit is a dedicated controller for the V-1200HD multi-format video switcher. Connecting the unit to a V-1200HD using an Ethernet cable lets you

control the operation of the V-1200HD from the unit.

* Use a Cat5e or higher shielded Ethernet cable for connection. Crossover cables and straight cables are both supported.

Conventions in this manual

In order to explain the operations as clearly as possible, this manual uses the following conventions.

5 Text enclosed in square brackets [ ] indicates the name of a button or a knob, such as the [AUTO] button, [VALUE] knob.

5 Text enclosed in angle brackets < > indicates the name of a button that appears in the screen, such as <VIDEO>.

5 Touching the monitor with your nger is referred to as “tapping.”

Before using this unit, carefully read “USING THE UNIT SAFELY”

(p. 3) and “IMPORTANT NOTES” (p. 5). After reading, keep the

document(s) including those sections where it will be available for

immediate reference.

Roland V-1200HDR User Manual
