May, 2007 V-SYNTH/GT
Exploded View (Plain 2) Parts List
No. Part Code Part Name Description Q’ty
a 40011101 SCREW 3X8 BINDING TAPTITE B BZC 12
b 40011312 SCREW 3X8 BINDING TAPTITE P BZC 6
No. Part Code Part Name Description Q’ty
a 40011101 SCREW 3X8 BINDING TAPTITE B BZC 28
b 40011312 SCREW 3X8 BINDING TAPTITE P BZC 4
j 40016590 NYLON RIVET NRP-345 BLACK 2
No. Part Code Part Name Description Q’ty
d 40011123 SCREW 4X8 BINDING TAPTITE B BZC 19
e 40013001 SCREW M4X8 PAN MACHINE W/SW+PW BZC 5
i 40012501 SCREW M4X12 BINDING TAPTITE P FE BZC 1
