Roland V-Synth GT - Exploded View (Plain 1) Parts List

9
May, 2007 V-SYNTH/GT
Exploded View (Plain 1) Parts List
No. Part Code Part Name Description Q’ty
a 40011101 SCREW 3X8 BINDING TAPTITE B BZC 4
b 40011312 SCREW 3X8 BINDING TAPTITE P BZC 5
c 40237101 SCREW M3X8 PAN MACHINE W/SW+SMALL PW BZC 5
d 40011123 SCREW 4X8 BINDING TAPTITE B BZC 2
g 40010345 SCREW M4X10 BINDING MACHINE FE BZC 1
h 40011745 HEX NUT M4 SPRING NUT FE ZC 1
No. Part Code Part Name Description Q’ty
f 40454045 SCREW 3X8 FLAT TAPTITEB NI FLANGE SOCKET 8
No. Part Code Part Name Description Q’ty
b 40011312 SCREW 3X8 BINDING TAPTITE P BZC 10
No. Part Code Part Name Description Q’ty
a 40011101 SCREW 3X8 BINDING TAPTITE B BZC 4
b 40011312 SCREW 3X8 BINDING TAPTITE P BZC 7
