Panel Descriptions
Top Panel
12 [MENU] button
Switches the menu screen between visible and hidden.
13 [EXIT] button
Exits a menu level or cancels an operation.
14 [VALUE] knob
Turn
Selects the menu parameters, switches between
parameters shown at the bottom of the display, and edits
their values.
Press
Conrms the menu item you selected or the value that
you edited.
15 PinP & KEY 1–2
This uses PinP and KEY 1–2 layers to composite video using PinP,
or picture-in-picture.
[PVW] buttons
Turns the inset screen preview output on/o.
[PGM] buttons
Turns PinP composition on/o.
[POSITION H] knob
Adjusts the horizontal position of the inset screen.
By turning the knob while pressing it, you can adjust the size of
the inset screen.
[POSITION V] knob
Adjusts the vertical position of the inset screen.
By turning the knob while pressing it, you can adjust the zoom of
the video shown in the inset screen.
16 [MONITOR] button
Switches between video signals to monitor on the built-in display
(monitor).
Button Explanation
MULTI-VIEW
The nal output video, preview output video and the
videos allocated to the VIDEO SWITCHER [1]–[6] buttons
are shown in sections of the display.
PROGRAM Shows the nal output video.
AUDIO LEVEL Shows the audio level screen in the display.
STILL-VIEW
Shows the loaded still images in 16 separate sections on
the display.
* The settings described above are the factory defaults. You can also
assign dierent functions to the button.
17 [OUTPUT FADE] button
The nal output video and audio fade in/out.
Lit Fade-out completed
Blink Fading-in/out
Unlit Normal output
* The settings described above are the factory defaults. You can assign
dierent functions to the [OUTPUT FADE] button.
18 DSK
This uses DSK layer to composite video using a downstream keyer.
[PVW] button
Turns the preview output of the DSK compositing result on/o.
[PGM] button
Turns DSK composition on/o.
19 PANEL
[SETUP] button
Shows the setup screen in the display.
20 MODE
The functions of the VIDEO SWITCHER [1]–[6] buttons change
according to the mode you select when pressing the buttons.
[INPUT SELECT] button
Use the VIDEO SWITCHER [1]–[6] buttons to select the video
source to send to the PGM bus or the PVW bus.
[AUX] button
Use the VIDEO SWITCHER [1]–[6] buttons to select the video signal
to send to the AUX bus.
[SCENE MEMORY] button
Use the VIDEO SWITCHER [1]–[6] buttons to recall the scene
memories (which contains the registered settings for video, audio
and so on). Long-press the VIDEO SWITCHER [1]–[6] buttons to
register the current settings in a scene memory.
[MACRO] button
This switches the function of the VIDEO SWITCHER [1]–[6] buttons
to execute macros (a series of recorded operations).
21 TRANSITION
Selects the video transition eects.
[MIX] button
The two videos are mixed as the transition occurs.
[WIPE] button
The next video moves across to replace the original video.
[SPLIT] button
Here’s how to composite two videos in dividing the screen into
left/right or upper/lower.
