Figure 6-11 Pedal assist sensitivity setting interface
6.12 Pedal assist strength setting
12P is the Pedal assist strength setting. The Pedal assist strength is the relative strength of the PWM signal from thecontroller when start to activate pedal assist. The adjustable range is 0 ~ 5. 0 is the weakest strength and 5 is the strongest.
Press to enter the parameter changing state. Press the
/
to select the parameter and press to save the parameter setting and return to the personalized parameter setting interface.
Figure 6-12 Pedal assist Start-up intensity setting interface
6.13 Number of pedal assist sensor magnets setting
13P is the number of pedal assist sensor magnets setting. The adjustable range: 5~12 pcs.
Press to enter the parameter changing state. Press the
/
to select the parameter and press to save the parameter setting and return to the personalized parameter setting interface.
