Roller Polo User Manual

Fig. 2
L
L
L
R
8
9 9
Fig. 3
Fig. 4
10, ⅜ 30 ● ● 153155
12, 10 U, ½ 36 ● ● ● 153160
14, 12 U 50 ● ● ● ● 153170
15, 12 U, ⅝ 55 ● ● ● 153175
16, 14 U 55 ● ● ● ● 153180
17, 15 U 60 ● ● 153185
18, 14 U, 15 U, 16 U, ¾ 72 ● ● ● ● 153190
20, 18 U 79 ● ● ● ● 153195
22, 18 U, ⅞ 86 ● ● 153200
25, 26 88 ● 153205
32 128 ● 153210
Biegesegment
für Rohre
Ø mm/Zoll
(1)
Biege-
radius
1)
mm
(2)
Geeignet für (3)
Art.-No.
Cu Cu-U St-U St V
1)
Biegeradius mm der neutralen Achse des Bogens (DVGW GW 392)
Cu: weiche Kupferrohre, auch dünnwandig
St-U: ummantelte C-Stahlrohre der Pressfitting-Systeme EN 10305-3 (DIN 2394)
St: weiche Präzisionsstahlrohre EN 10305-1, EN 10305-2, EN 10305-3 (DIN 2391–2394)
U: ummantelt
V: Verbundrohre der Pressfitting-Systeme
10
11
3
