rollibot puro - Cleaning the Floor Tool Agitator

5.5 –Cleaning the Floor Tool’s Agitator
Detach the Floor Tool from the
vacuum. Use the notch to turn the
latch’s lock counter-clockwise.
Step 1
Remove the latch.
Step 2
Lift the agitator up slightly and
carefully pull the belt o.
Step 3
Lift the agitator out, hold it over a
waste bin, and shake o any dust.
Pull or cut out any entangled debris
as needed.
Step 4
Replace the agitator, pull the belt
back on the right side, and replace
the latch.
Step 5
Use the notch to turn the latch’s
lockclockwise.
Step 6
1
2
Belt
10
