Assemble the Handle Bars
1. Remove the screw (26) and nut (24) from the steering axle.
2. Slide the handle bars (9) onto the steering axle. Ensure the holes on the
handle bars align with the holes on the steering axle.
3. Insert the screw and nut into the handle bar assembly and tighten with a
screwdriver.
4. Carefully slide the handle bar wire connector into the wire compartment
where the motorcycle wire connector is located.
26
24
