Note: Please place the and

template on the inside of the side

rail, and then drill according to the

instructions on the template

B. Right Side Rail

B. Left Side Rail

- 10 -

Template

NOTE: Be sure to follow the instructions on the template exactly for

drilling and marking

Note: Align the paper template with the edge

of the B. side rail according to the orientation

shown in the figure below.
