- 13 -
Mount to the outside of the
side rail.
To help you achieve this position，
cut a piece of wood 5/16" thick and
place it under the BALL ONLY
while you screw the plate in place.
BALL STUD PLACEMENT
LOWER BALL STUD PLATE:
FEMALE PIVOT：
Mount to the inside of side rail with
bushing through the 1" hole.
5/16
B. SIDE RAIL
This page pertains to the orientation and mounting
positions of the lower ball stud plates and female
pivots, USE WITH PAGES 14,15,&16
