2. Characteristics
1) Super magnet attaching installation;
2) Built-in antenna;
3) Track by SMS or GPRS;
4) Real time tracking at intervals;
5) Resend data from signal dead zone;
7) Low power alarm;
8) Overspeed alarm;
9) Geo-fence alarm;
10) Tired driving alarm;
11) History playback;
12) Mileage statistics;
13) Reports statistics;
14) Remotely update firmware;
15) Waterproof.
2.1 Red LED (Recharge battery light status)
LED Status
Meaning
Keep on
Charging
Turns green
Charged
2.2 Orange LED (GPS status indicator)
LED Status
Meaning
Fast flashing(every 0.1s)
Initialize
Bright 0.1s,dark 2.9s
GPS signal normally
Bright 1s,dark 2s
No GPS signal
2.3 Green LED（GSM status indicator）
LED Status
Meaning
Always keep on
Calling or dialing
Fast flashing(every 0.1s)
Initialize
Bright 0.1s ,dark 2.9s
GSM signal normally
Bright 1s,dark 2s
No GSM signal
2.4 Specification:
Items
Parameters
GSM Module
Quectel M35
GSM Frequency
850/900/1800/1900 MHZ
LBS Positioning Accuracy
100-500m
3G Antenna
Built-in
GPS Chipset
U-blox 7020
