Safe-T-Scope
®
Backup Camera System STSK7465
STSK7465 SAFE-T-SCOPE
®
7" COLOR BACKUP CAMERA SYSTEM
TABLE OF CONTENTS
2 11
STSK7465 Safe-T-Scope
®
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Components List and description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Camera Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Monitor Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 -7
Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
System Technical Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
How To Set Your Monitor To Your Requirements . . . . . . . . . . . . . . . . . . . . . . 10
Rosco Vision Systems introduces a revolutionary new backup camera system for commercial vehicles.
The STSK7465 Safe-T-Scope
®
backup camera system utilizes a 7'' inch monitor to display a 16:9 LCD
screen when the vehicle shifts into reverse. This monitor allows the driver to see obstructions behind
the vehicle for added convenience and safety.
The camera has an advanced CCD image sensor able to process excellent views under dark and light
conditions. A 120° diagonal field of vision yields superb coverage behind the vehicle, and complies
with the latest U.S. DOT guidelines when installed properly.
