Safe-T-Scope
®
Backup Camera System STSK7465
Image device: Sony ¼" CCD
Pixels: 270,000
TV lines: 420
InfraRed LED's: 18 High-Output
Minimum illumination: 0 Lux (infrared LED's on)
Night vision range: 30 feet
Video Output: 1.0 Vp-p, 75 Ohm
Shock rating: 100G
Vibration rating: 15G
Field of view: 120°
Operating temperature °F (°C): -4° to +140° (-20° to + 60°)
Storage temperature °F (°C): -40° to +176° (-40° to + 80°)
Weight: .6 lb.
Dimensions W x H x D: 3" x 2" x 2"
• Please read this manual carefully before using the product.
• This system is intended as an aid to safe reverse operation.
• Drivers must always use extreme caution when operating a vehicle.
• Specifications subject to change without prior notice.
• Keep all cables AWAY from rotating and electrically noisy components.
•
Make sure all cables are fastened properly so that you can prevent wire chafing, kinks, cuts, etc...
• Always consult your dealer when fitting any electrical or electronic equipment to a vehicle fitted
with a CAN-bus or multiple system.
WIRING NOTES
SYSTEM TECHNICAL SPECIFICATIONS:
STSM254: (Includes STSK7465/PHAR, BAS4515, STSDF1000)
STSC141: ( Includes Sunshade and Mounting Hardware)
4 9
• To prevent electrical shock, DO NOT
OPEN MONITOR CASE.
• Avoid exposing monitor to water, rain,
moisture etc.
• Do not disassemble the camera.
This voids the warranty.
• Disassembling the camera will
compromise the waterproof seal.
WARNING
65’ Heavy Duty w/ Twist - Lock Connectors
STSH341: (Included in Kit)
Screen size (diagonal): 7"
Maximum No. of cameras: 1 Inputs/Channels
Screen ratio: 16:9
Contrast ratio: 500:1
Video system: NTSC
Voltage input: 12 ~32 Vdc
Operating temperature °F (C°): 5° to 149° (-15° to +65°)
Storage temperature: -4° to +158° (-20° to + 70°)
Shock rating: 100g
Vibration Rating: 6g
Speaker Impedance: 8 Ohms
Weight: 0.9 Lb.
Dimensions W x H x D: 5.7" x 4.9" x 1"
