User Manual
3. Install Motherboard & Add-in Card
6
© All rights reserved by Rosewill
3-1 Place the motherboard standoffs based on manufacturer specs.
3-2 Secure the motherboard with screw-A.
3-3 Unscrew to remove the slot cover. 3-4 Install the add-in card and secure with screws.
* screw A
CHALLENGER-
CASE
