Rosewill CULLINAN MX Series User Manual

Quick User Guide
7
CULLINAN MX Series
Gaming Case
6. Fan Installation
The Rosewill CULLINAN MX is equipped with a fan controller on the I/O ports to control
up to 7 fans with the fan hub (Figure 6). Follow the instructions below to correctly connect
the fan and controller to the fan hub.
a. Connect the Fan Hub:
Connect the 4 pin Molex connector to PSU.
b. Connect the Fans:
Connect the 3 pin connector to the Fan Hub.
The CULLINAN MX features fan speed control directly through the Front I/O Port:
"L" = Low: fans spin moderately without LED lights (Eco Mode).
"S" = Stop: fans stop spinning and LED lights turn off.
"H" = High: fans spin at full speed (1200 RPM) with LED lights on.
Fan Control
6

Rosewill CULLINAN MX Series Specifications

General

Brand	Rosewill
Model	CULLINAN MX Series
Category	Enclosure
Language	English
