Front I/O Diagram
Accessory Kit
Figure Part’s Name FunctionQty
Screw-B
Screw-C
6
4
8
10
SRM-01
USB 2.0
HD Audio In / out
Reset Button
USB 3.0
Power Button
M/B Standoff
Screw-A
Motherboard
Motherboard
Power Supply
5.25” Device
3.5”/2.5” HDD/SSD
