Ross CDA-50 - PARTS LIST - CDA-50

© 2017 CHARLES ROSS & SON COMPANY
16
PARTS LIST - CDA-50
1
1
RC3200A HYDRAULIC LIFT CYLINDER, AIR/OIL
1
1A
4A0141 RESERVOIR AIR/OIL, HYDRAULIC
1
1B
4A0399 VALVE, HAND, OIL CONTROL, 2-WAY
1
1C
4A0398 VALVE, AIR CONTROL, 3-WAY
1
1D
4A0125 MUFFLER AIR
1
1E
4R0048 HOSE, HYDRAULIC, 150PSI
ENDS
1
1F
4S0004 VALVE BALL NPTF BRASS 150PSI
1
1G
PACKING, CHEVRON, HYDRAULIC CYLINDER
1
2
RB2011 ROD, NON-ROTATION, CDA-50
1
3
5Q0028 LIMIT SWITCH, HEIGHT
1
4
4A0005 ARM, ROLLER, LIMIT SWITCH
1
5
5Q0028 LIMIT SWITCH, CAN LOCK
1
6
4A0004 ARM, LEVER, LIMIT SWITCH
2
7
7G0024 PIN QD, RECESSED PUSH-BUTTON, CAN LOCK
2
8
4A0396 CHAIN, 8" LG
1
9
RD1384A BONNET, CDA-50
1
10
RC3175 COVER, BONNET, CDA-50
1
11
4A0186 SIGHT GLASS LIQUID LEVEL BRASS .500 NTPF 100PSI
1
12
7F0052 FITTING, GREASE, 1/8" NPTM
1
13
5A0048 MOTOR 5HP, 1800RPM 3/60/230/460V (2-WING ANCHOR)
1
14
4L0041 SHEAVE,TAPER LOCK, (DISPERSER SHAFT)
1
15
4F0016 BUSHING TAPER-LOCK (ANCHOR MOTOR)
2
16*
4C0012 V-BELT, (ANCHOR)
1
17
4N0043 GEAR REDUCER
1
18
4L0081 SHEAVE TAPER-LOCK (ANCHOR, GEAR REDUCER)
1
19
4F0016 BUSHING TAPER-LOCK (ANCHOR MOTOR)
1 20 RA2168 PLATE, PUSHER, DISPERSER MOTOR, CDA-50
1
21
5A0029 MOTOR 10HP, 1800RPM 3/60/230/460V (DISPERSER)
1
22
4L0092 SHEAVE TAPER-LOCK (DISPERSER MOTOR)
1
23
4F0023 BUSHING, TAPER-LOCK, (DISPERSER MOTOR)
2
24*
4C0009 BELT (DISPERSER MOTOR)
1
25
4L0090 SHEAVE,TAPER LOCK, (DISPERSER SHAFT)
1
26
4F0019 BUSHING, TAPER-LOCK, (DISPERSER SHAFT)
1
27
RC3178 BEARING HOUSING, ANCHOR, CDA-50
1
28
RC3176 SHAFT, ANCHOR, CDA-50
1
29
4B0026 BEARING, BALL, UPPER, 2 SEALS (ANCHOR)
