Ross TC700MC - 5.9 RETURN SPRING;CAM ASSEMBLY

5.9 RETURN SPRING/CAM ASSEMBLY
MN700-MC0010
5-9
MN4126201B.DWG
RETURN SPRING/CAM ASSEMBLY
SCREW HHC 1/4−20x2.00"LG SCREW HHC 1/4−20x1 7/8"LG RETURN SPRING MOUNT OUTER NUT HEX LOCKING 3/8−16 RETURN SPRING MOUNT INNER BAR−RETURN SPRING MOUNT SCREW HHC 3/8−16x1 3/4"LG
9
11 10
WASHER LOCK Ø1/4" CAM PLATE MOTOR GEAR
4 6 8 7 5
SPRING
2 3 1
02219020 11018520 11040074 11017718 11450609 11018519 02219010 01219030 05178000 01219300 14100094
