MN700-MC0010
7-6
I. Replace unlock cushion
J. Make sure that the guide raisers (page 5-10, item 18), on the main uprights, are seated all the way
down on the stabilizer bars and spacers (page 5-11, items 29,30)
K. Make sure toggle assembly is centered on toggle rod.
L. Check mechanism for free movement. Toggle assembly should pivot up and down approximately 1/8".
M. Turn motor coupling (in direction of arrow) so machine makes two complete cycles. Check for proper
clamp and guide operation throughout cycle.
