Reader Operation
16 AYC-Ex5/T65 Series Installation and Programming Manual
3. Reader Operation
The AYC-Ex5/T65 series can function both as a reader and as a
controller. If the unit is connected to standard access controller, it
functions as a reader, indicated by one beep immediately after
power-on reset.
The use of a proximity card is not relevant for the AYC-E55
model.
3.1 General
The default mode of the reader is Standby mode. In Standby mode,
the unit is ready to receive data from a presented proximity card or
an entered PIN code.
Programming the reader
is done via the unit's keypad driven
programming menu system (Section 3.2).
Keypad data can be sent via one of eight keypad transmission
formats. For more information, see Section 3.2.3.
Rosslare proximity cards presented to the reader can output card
data as Wiegand 26-Bit, Clock & Data, and Wiegand + PIN. See
Section 3.2.4 for more information.
When the reader is in Standby mode, the left LED
is red and the right LED is off.
When the reader is in Programming mode, the
left LED is off and the right LED is green.
When a proximity card is presented or a keypad
entry is being transmitted, the left LED flashes
green.
