Technical Specifications
AYC-F/Gx4 Series Installation and Programming Manual 11
2. Technical Specifications
Specifications AYC-F54 AYC-F64 AYC-G54 AYC-G64
Electrical Characteristics
Power Supply Type
Linear (recommended)
Operating Voltage
Range
5 to 16 VDC (when used as a controller, provided by
the secured intelligent power supply)
Input Current
Standby (12 VDC)
75 mA 105 mA 75 mA 105 mA
Input Current Max
(16 VDC)
110 mA 140 mA 110 mA 140 mA
LED Control Input
Dry contact N.O.
Tamper Output
Open collector, active low, 32 mA max sink current
Cable Distance to
Host Controller
Up to 150 m (500 ft) using an 18 AWG cable
Max. Proximity Card
Read Range*
N/A 80 mm
(3.2 in.)
N/A 80 mm
(3.2 in.)
Proximity Card
Modulation
N/A ASK at 125
kHz
N/A ASK at 125
kHz
Proximity Card
Compatibility
N/A EM cards N/A EM cards
Card Transmit
Format (Reader)
N/A Wiegand
26-Bit or
Clock &
Data
N/A Wiegand 26-
Bit or Clock
& Data
Keypad Transmit
Format (Reader)
Programmable PIN code formats
LED Indicators
Two tri-colored LEDs
Communication
Data1/C1, Data0/C2 – open collector, 5 V termination
* Measured using a Rosslare proximity card or equivalent. Range also depends
on electrical environment and proximity to metal
.
