Rostra UNIVERSAL LUMBAR - Universal Lumbar Parts List; Universal Lumbar Parts Diagram

PARTS LIST
PARTS DIAGRAM
BLADDER SWITCH PUMP/POUCH HARNESS HDW PKG
250-02038 Standard 250-02054 250-02047 250-02046 250-02044
250-02042 Front Mount
PAGE 2
12in. (30.5cm)
10.25in. (26.0cm)
Standard Bladder Assy
(250-1453 KIT)
Switch Assy
Pump/Pouch Assy
Front Bladder Assy
(250-1454 KIT)
Fused Harness
Main Harness
Pump/Pouch Connector
