Rotary 300 Series User Manual

10
MANUAL LOWERING
MANUAL LOWERING
If the car lift cannot perform lowering operations because of power supply interruption, faulty hydraulic valves
or electric trouble in the system, the lift can be lowered manually. For manual lowering operation (emergency),
performthefollowing:
•Makesuretherearenoobstaclesblockingtheloweringphase;rememberthatthecarliftmaynotbelifted
again to remove possible obstacles.
•Disconnectmainpowersupply.
•Removemanualloweringcap.
Note:Manuallowering(emergency)operationsshouldbepreformedbyauthorizedpersonnelspeciallytrained
for operating the car lift only.
•Loosenthemanualoperators(OM)(A1-B1)
1/2 turn.
•Emergencyloweringhasstarted;speedcanbeincreasedordecreasedaccordingtotheopeningofscrews.
OM-A2
Manual
Lowering
Cap
Manual
Lowering
Cap
OM-B2
