Rotex Solaris RPS3 25M User Manual

7 x Hydraulic system integration
51
FA ROTEX Solaris RPS3 25M - 03/2010
7.2 Short designations
Short name Meaning Remark Order No.
SCS 328/14/0 Sanicube Solaris INOX 16 50 10-44
SCS 538/16/0 Sanicube Solaris INOX 16 45 16-44
SCS 538/16/16 Sanicube Solaris INOX 16 45 17-44
SCS 538/0/0 Sanicube Solaris INOX 16 45 15-44
HYC 343/19/0 HybridCube 14 05 07
HYC 544/19/0 HybridCube 14 05 01
HYC 544/32/0 HybridCube 14 05 02
GSU S GasSolarUnit with solar heating support
GSU 520S-e 15 71 11-44
GSU 520S F-e 15 71 12-44
GSU 530S-e 15 71 22-44
GSU 530S F-e 15 71 24-44
GSU GasSolarUnit without solar heating support
GSU 320-e 15 70 28-44
GSU 320 F-e 15 70 29-44
A1-Inline A1 BO 15 bio-e 15 49 17-44
A1 BO 20 bio-e 15 49 18-44
A1 BO 27 bio-e 15 49 19-44
A1 BO 35 bio-e 15 49 20-44
A1 BG 25-e 15 59 00-44
A1 BG 40-e 15 59 01-44
1Cold water
2Hot water
3 Heating inflow
4 Heating return flow
5 Mixer circuit Optional
6 Circulation Optional
7 Check valve, return valve on site
7a Non-return valve (for storage tank connections) Accessories 16 50 70
8 Solar circuit
9 Fluid pipe for coolant circuit for HPSU Bi-Bloc heat pump
10 Gas pipe for coolant circuit for HPSU Bi-Bloc heat pump
11 Storage tank flow
12 Storage tank return
13 Equalising pipe
14 Input heating support
15 Output heating support
UV1 3-way diverter valve
UV2 3-way diverter valve Accessories 15 60 44
AMK1 Mixer group Accessories 15 60 44
BV Overflow valve on site
C Circulation pump for inside unit for HPSU Bi-Bloc heat pump
FLS
Flow sensor, Solaris FlowSensor FLS20 or alternative type according to
Table 5-1 (Flow rate and flow temperature measurement)
Accessories
16 41 07
FLG Solaris FlowGuard regulating valve with flow indicator 16 41 02
HP-TR Main controller for HPSU heat pump Supplied with HPSU.
Mi 3-way-mixer with drive motor Supplied with AMK1.
P
Mi
Mixer circuit pump Supplied with AMK1.
P
K
Boiler circuit pump Supplied with GSU/A1-Inline.
PS
S
Storage tank charging pump (only if there are several hot water storage tanks
in a linked system)
on site
P
Z
Circulation pump
on siteP
S1
Circulation pump
P
S2
Booster pump
RPS3 25M Control unit Solaris Accessories 16 41 11-44
RLB Return temperature limiter on site
